Epcos B32343L4052A040 Phicap Normal Duty Capacitor
Epcos
Tdk
Power Quality Solutions
Phicap
Product Number: B32343L4052A040
| Attribute | Details |
|---|---|
| Brand | Epcos |
| Manufacturer | TDK |
| Product Type | Power Quality Solutions |
| Model | B32343L4052A040 |
| Kvar | 5.0 Kvar |
| Voltage | 440 Volts |
| Frequency | 50 Hz |
| Phase | 3-Phase |
| Temperature Category | -25°C to +70°C |
| Insulation Level | 3/-KV |
| Rated Current | 6.6 Amps |
| Discharge Device | Resistor E |
| IEC Standard | IEC 60831-1 |
| Dielectric | Mpp 'Sh' |
| Impregnant | Npcb |
| Overpressure Disconnector | 31N18 |
| Serial Number | 118068324189 |
| Technical Data | Phicap Rou 440V 50/60Hz-5/6Kvar 3Ph |
| Capacitance | 3 X 27.4 µF |
| Connection | Delta |
| Weight | 620 g |
Epcos B32343L4052A040 Phicap Normal Duty Capacitor: This is the high-performance capacitor engineered to provide the stability of power factor correction across a variety of industrial and commercial applications. One of the leading companies manufacturing power quality solutions in the world designed the B32343L4052A040. The capacitor in question was specifically developed for middle voltage power systems. It would be able to optimize performance in compensating for reactive power. This can prevent energy losses as well as generally upgrade the overall efficiency of an electrical system. Therefore, with a nominal power rating of 5.0 Kvar and a voltage rating of 440V, it is apt for use in various electrical installations requiring efficient management of energy.
1. Power Rating: 5.0 Kvar which will be helpful to correct power factor mildly in an industry
2. Voltage Rating: 440 Volts will work with the medium rating of voltage quite efficiently.
3. Frequency: 50 Hz, so it is at par with a normal power supply of the world
4. Phase: Designed especially for 3-phase power system. Thus, provides a balanced output.
5. Temperature Range: -25 to +70 which enables operation over an extensive range of ambient conditions that makes it operational with maximum efficiency.
6. Level of Insulation: 3/-KV. It has high insulation strength that ensures its safe operation in extreme environments.
7. Rated Current: 6.6 Amps, it can take more current to provide efficient power compensation.
8. Discharge Device: Resistor E is provided to safely discharge the capacitor after disconnection.
9. Dielectric Material: Mpp 'Sh' dielectric is used which improves the durability and performance of the capacitor.
10. IEC Standard: Up to IEC 60831-1. The capacitor is manufactured in accordance with international quality standards and safety standards.
11. Impregnant: Npcb impregnant is used here. It is environment friendly and safe.
12. Overpressure Disconnector: It is provided with 31N18 type overpressure disconnector which nullifies the risk from internal over-pressures and pressures.
13. Weight: 620 g, Compact and lightweight - Easy to instal and handle.
1. Power Factor Correction: This is generally used in the industrial plants, commercial buildings, and substations to improve power factor, to minimize energy loss, and lower electricity costs.
2. HVAC Systems: It is applied in the large HVAC systems, where it helps in power factor improvement; subsequently, less energy is consumed, and their cost is decreased.
3. Motor and Pump Systems: In motor and pump systems, power factor correction helps in easy running and saving of energy.
4. Renewable Energy: It is suitable for renewable energy-based applications like wind or solar power to maximize the energy distribution and reliability of the system.
5. Industrial Equipments: It is suited for big factories, manufacturing units, and large industrial systems to ensure efficient power management and minimize the consumption of energy.
6. Commercial Power Systems: This is appropriate for commercial structures, retail stores and offices, to improve the effectiveness of energy usage and to reduce the reactive power needed from the supply grid.
The B32343L4052A040 Phicap Normal Duty Capacitor from Epcos is a reliable and efficient solution designed to improve power quality, reduce energy costs, and ensure safe operating of electrical systems in every use case.
