Hyundai Hian 20 3 Poles Air Circuit Breaker 2000A Cat B 50/60Hz
Hyundai Heavy Industries Co., Ltd.
Air Circuit Breaker
Hian 20
3 Poles
In= 2000A
Ui= 1000V
50/60Hz
Uimp=12Kv
| Specification | Details |
|---|---|
| Product Name | Hyundai Hian 20 3 Poles Air Circuit Breaker 2000A Cat B 50/60Hz |
| Manufacturer | Hyundai Heavy Industries Co., Ltd. |
| Type | Air Circuit Breaker |
| Model | Hian 20 |
| Poles | 3 |
| In | 2000A |
| Ui | 1000V |
| Frequency | 50/60Hz |
| Uimp | 12Kv |
| Category | Cat.B |
| Ics | 100% Icu |
| Standards | En/Iec 60947-2, Vde 0660, Gost R 50030.2-99 9/1-2000 |
| Voltage (600/690V) | 65Ka |
| Voltage (220/500V) | 70Ka |
| Icw (70Ka/1S) | 70Ka/1S |
| Icw (65Ka/1S) | 65Ka/1S |
| Model Code | Apr-il-gl |
| Features | Over-current & Ground Fault Trip |
| Product Code | Ian20/3P |
| Type | Draw-out Type (2000Af) |
| Motor Charge | Ac110V |
| CT | 2000/0.2A |
| Io | 2000 |
| Shunt | Ac100~150V |
| Additional Components | Fixing Block, Arc Barrier/Arc Shield |
| Voltage | 220V |
| Model Code (Hans-m1) | Dc110V/125V |
| Component Code | Djm 10E12 |
| Serial Code | Apr1002-0298 |
| Country of Origin | Made In Korea |
| Weight | 90.400 Kg |
The Hian 20 3 Poles Air Circuit Breaker, manufactured by Hyundai Heavy Industries Co., Ltd., exemplifies advanced technology and robust manufacturing designed to meet the rigorous demands of industrial and commercial applications. With a focus on reliability, safety, and versatility, this breaker is customized to safeguard electrical circuits effectively. At its core, the Hian 20 features a nominal current rating (In) of 2000A and an operational voltage (Ui) of 1000V, ensuring it can manage substantial electrical loads with ease. This makes it ideal for use in power distribution networks, manufacturing plants, and other high-energy environments where dependable circuit protection is vital.
Compliant with international standards such as EN/IEC 60947-2 and VDE 0660, as well as meeting local certifications like GOST R 50030.2-99, the Hian 20 guarantees adherence to harsh quality and safety regulations across different markets. Its Cat.B rating signifies its ability to handle short-circuits currents (Icu) at 100% efficiency, ensuring reliable operation even under extreme fault conditions. The Hian 20 impressive interrupting capacity (Icw) of 70kA/1s at both 600/690V and 65kA/1s at 220/500V underscores its capability to swiftly interrupt fault currents, minimizing potential damage and downtime. Equipped with over-current and ground fault trip functionalities, it offers enhanced protection against electrical faults, further bolstering operational safety.
Designed for flexibility and ease of maintenance, the Hian 20 is a draw-out type breaker (2000Af), facilitating straightforward installation and replacement processes without disrupting ongoing operations. Its motor charge capability (AC110V) ensures reliable operation of its mechanisms, while features like the arc barrier/shield and fixing blocks enhance safety during maintenance procedures. In terms of applications, the Hian 20 excels in situations requiring high-performance electrical protection, such as substations, data centers, industrial plants, and critical infrastructure facilities. Its robust construction and comprehensive protective features make it suitable for various operational conditions, including both AC and DC applications, supported by its voltage ratings and interrupting capacities. Manufactured with precision in Korea, each Hyundai Hian 20 breaker undergoes rigorous testing and quality assurance checks to guarantee reliability and longevity. With a weight of 90.400 kg, it balances large durability with manageable installation and maintenance requirements, ensuring operational continuity and safety across its service life.
For a comprehensive and reliable solution in high-capacity circuit protection, consider this product the Hyundai Hian20 Air Circuit Breaker 3 Poles 2000A 50-60Hz . Designed to handle demanding electrical conditions, this circuit breaker ensures optimal safety and performance for your applications.
