Murr mps5-230/24 switch mode power supply
murr elektronik
power division
product of the power + series
switch mode power supply
m
| Feature | Description |
|---|---|
| Brand | Murr Elektronik |
| Product Name | Switch Mode Power Supply |
| Series | Power + |
| Model | MPS5-230/24 |
| Art. No. | 85053 |
| Input | L/PE 100-240V 50/60Hz 1.9-0.95A |
| Output | 24V DC 5A SELV |
| IP Rating | IP20 |
| Tightening Torque | 0.5-0.6 Nm |
| Insulation Temperature Rating | 75°C |
| Reference Numbers | MH 29098, 29098 MFC WHSE3 2G1 E02, 29098 MFC WHSE3 201 E02 |
| Wire Size (Cu) | 1.5-2.5 mm² / 16-12 AWG |
| Weight | 888 gm |
| Country of Origin | Finland |
One of the rugged and efficient solutions from the Power + series is the Murr Elektronik MPS5-230/24 Switch Mode Power Supply. Electrical source power has been designed to transfer input voltages - 100-240V AC to a stable output 24V DC with a maximum output current of 5A, hence usable for a wide variety of devices and systems. The MPS5-230/24 is thus best suited for applications and environments in which high reliability of performance as well as safety is a must. The device has solid foreign objects protection as its construction can withstand IP20 rating, and by having 75°C insulation, its survivability under high-demand conditions is enhanced. Key Features/Application of MPS5-230/24 The MPS5-230/24 plays the main role in a number of industrial applications by providing versatile applications within many fields.
1. High Voltage Range : The range of input voltages is from 100-240V AC, thereby the device can operate on a variety of power sources.
2. Robust Output : The output is stable 24V DC with the current of 5A, which is very suitable for most applications.
3. Compact Form : The unit form is optimized for space-saving applications and is, thus, ideal for various configurations.
4. IP20 Protection Rating : Provides protection against solid objects in indoor environments.
5. High Insulation Temperature Rating : 75°C rated to ensure that the equipment works safely even in thermal conditions.
6. Efficient Power Conversion : Switch-mode technology enables high efficiency with low energy losses in operation.
7. Easy Installation : Has a tightening torque specification of 0.5-0.6 Nm for reliable wiring connections.
8. Flexible Wire Sizes : Supports from 1.5 to 2.5 mm² / 16 to 12 AWG wire sizes.
9. Lightweight Design : Weighing only slightly more than 888 grams, it is light enough to be managed and installed without exertion.
10. Reference Number Identification : Includes various reference numbers (MH 29098, 29098 MFC WHSE3 2G1 E02) for easy identification and compatibility checks.
1. Industrial Automation : Power supply for control systems, sensors, and actuators in various manufacturing areas.
2. Robotics : Provides reliable power for robotic systems, ensuring consistent operation during tasks.
3. Machine Tools : Applications involve powering CNC machines or other automatically controlled machinery.
4. LED Lighting Systems : Drive LED lighting applications where a steady 24V output is required.
5. Telecommunications : Powers telecommunications equipment that ensures signal integrity and reliability.
6. Building Automation : It is an add-on for building management systems and controls heating, ventilation, and air conditioning controls.
7. Test and Measurement Equipment : Used in laboratories as power supply for test equipment and measuring devices.
8. Energy Management Systems : It is adaptable to energy monitoring and management systems so that efficiency is improved.
9. Control Panels : It is best used in control panels where reliable sources of power are required for numerous electronic components.
10. Transportation Systems : Powers the equipment that forms transportation applications, such as signaling and communication systems.
Power your industrial applications with confidence get the Murr Elektronik MPS5-230/24 Switch Mode Power Supply Like Related Products Click Here at Aeliya Marine today!
