Pepperl + Fuchs
Pepperl+Fuchs Khd2-ss1/Ex2 Isolation Switch Amplifier 20652S
69746
Only 1 left
Pepperl+Fuchs Khd2-ss1/Ex2 Isolated Switch Amplifier 20652S
Pepperl+Fuchs
Rs
K-serie/ Series
Khd2-ss1/Ex2
Part No: 20652S
Control Circuit
[Eex Ia] Iic
Ptb Nr. Ex-89.C.2073
Namur Din 19234
Operating Values:
Uo: Ca/Ac 8V
Jk: Ca/Ac 8Ma
Maximum Values:
Uo= 12.7V
Jk= 20Ma
P= 63.5Mw
Application [Eex Ia]Iic
Ca: 415 Nf
La= 2Mh
Output:
U: 250Vac
J: 2A
Cos ϕ: 0.7
U: 30 Vdc
Supply 11-12: 24Vdc ±15% 10%
Led 1.1, 2.1 Yellow
Led 1.2, 2.2 Red
Led 3 Green
Ambient Temperature 65°C
I-arbeitsstrom/Working Current Mode A
Ii-ruhestrom/Quiescent Current Mode R
285-396
Sev
[Eex Ia] Iib, Iic
Asev 90.1 C02719
Weight: 150 Gm
