Schneider Electric Lv426256 Circuit Breaker 80A
Schneider Electric India Pvt Ltd
Merlin Gerin
3P/4P Circuit Breakers And Switch-disconnectors
Compact Nsxm
Nsxm160B
P.Ref#: Lv426256
Ui 800V
| Item | Details |
|---|---|
| Product | Schneider Electric LV426256 Circuit Breaker 80A |
| Manufacturer | Schneider Electric India Pvt Ltd |
| Brand | Merlin Gerin |
| Type | 3P/4P Circuit Breakers and Switch-disconnectors |
| Series | Compact NSXM |
| Model | NSXM160B |
| Reference Number | LV426256 |
| Rated Voltage (Ui) | 800V |
| Impulse Voltage (Uimp) | 8 kV |
| Frequency | 50/60Hz |
| IEC/EN Standard | IEC/EN 60947-2 |
| Temperature Rating | 40°C |
| Category | Cat A |
| Rated Current (In) | 80A |
| Rated Current (Ir) | 56/80A |
| Breaking Capacity (Ii) | 1000A |
| Technical Codes | TC19342 TC19342010061 TC19337 |
| Additional Part Numbers | 998CSTN93PAX8S GB/T14048.2 12-00694-1 EAV94320 TC19341 11-00300-2 EAV16581 EAV95120 |
| Product Specification | 3P3D TM80D |
| Short-Circuit Protection | 25kA 380/415V |
| Technical Reference | TC-2019-W34-2 |
| Reference Number | 117442 |
| Description | Breaker NSXM 25kA TM80D 3P Busbar |
| Barcode | 3 606481 174420 |
| Country of Manufacture | Made in China |
| Weight | 1.150 Kg |
Schneider Electric LV426256 Circuit Breaker 80A made by Schneider Electric India Pvt Ltd under Merlin Gerin brand is used as an extremely efficient circuit breaking device designed for high-performance industrial and commercial applications.
This is due to its rated current of 80A, along with the maximum voltage rating of 800V, allowing it to carry heavy loads safely and efficiently. The short-circuit breaking capacity of 25 kA is found at 380/415V. It can therefore be used in lots of demanding positions within high-power systems. As designed for 50/60Hz systems, it is also available in IEC/EN 60947-2 compliance, thus giving utmost reliability and safety.
The LV426256 weighs 1.150 kg and is built in China, giving it an easy installation and integration into the existing electrical systems. The robust construction with the advanced features of this product is trusted to ensure dependable circuit protection for professionals.
1. Higher Current Rating : Can be as high as 80A. Ideally used in a wide range of industrial and commercial applications.
2. Voltage Rating : Attributable up to 800V. It can work with various electrical systems.
3. Short Circuit Protection : It offers a breaking capacity of 25 kA at 380/415V for efficient short circuit protection.
4. Compact Design : Designed for easy installation even in constrained spaces with robust performance.
5. Frequency Compatibility : Designed for use in either 50Hz or 60Hz systems.
6. Durable Construction : Engineered to perform well under arduous industrial environments for maximum lifespan
7. Lightweight Design : The solution weighs only 1.150 kg, hence friendly in regards to handling and mounting.
8. Effective Insulation : The Uimp rating is 8 kV, thus the performance of the product is guaranteed in any environment
9. Assurance of Quality : Schneider Electric is the manufacturer of this solution. It has a proud history of high standards in electrical solutions
10. Compliance with Standards : In terms of IEC/EN 60947-2 safety and reliability standards.
1. Industrial electrical systems : Applied in factories and manufacturing plants for protection in circuits.
2. Commercial buildings : Served in safety and reliability of electrical distribution panels.
3. Data centers : Applied in critical power systems to make sure there is nothing interrupted during services.
4. Renewable energy systems : Applied in solar and wind energy systems for effective protection.
5. HVAC equipment : applied in heating, ventilation, and air conditioning systems for circuit protection.
6. Pumping stations : Served in water and wastewater treatment facilities for reliable operation.
7. Process Control Systems : They are used in different types of process industries to ensure optimum working conditions.
8. Marine Applications : They are applied to shipboard electrical systems for safety and efficiency.
9. Construction Equipment : They are applied to heavy machinery to protect electrical components.
10. Transportation Systems : They are used in rail and public transportation systems.
Ensure dependable circuit protection with the Schneider Electric LV426256 Circuit Breaker 80A. Like Related Products Reach out to Aeliya Marine today for more details and customized solutions!
