Superior Electric Ss52 Synchronous Motor
Superior Electric
Slo-syn Motor
Synchronous Motor
Type: Ss52
| Attribute | Details |
|---|---|
| Brand | Superior Electric |
| Product Type | Slo-syn Synchronous Motor |
| Motor Type | Synchronous Motor |
| Model | SS52 |
| Phase | 1-Phase |
| Voltage | 240 Vac |
| Current | 0.2 Amps |
| Frequency | 50/60 Hz |
| Speed | 60/72 RPM |
| Connector Part Number | 223489-009 |
| Country of Origin | U.S.A. |
| Weight | 1.4 Kg |
The Superior Electric SS52 Synchronous Motor is one of the highly quality and reliable motors in terms of precision and efficiency for different applications in industry. It is one such model, the 1-phase synchronous motor by the name of SS52, with proven strength and consistent performance. As a brand name recognized in the motor technology range, Superior Electric manufactures the SS52 according to engineering that will meet up with systems requiring steady speed and synchronization, both for 50 Hz and 60 Hz frequency environments.
The SS52 Synchronous Motor has a light construction and is robust in its structure. These make it more suitable for usage in areas demanding low power consumption and stable operations. The motor operates on 240 VAC and is furnished with a very low current intake of 0.2 Amps. Hence, this could be ideal for applications with poor power availability.
1. Motor Type: Synchronous Motor Gives consistent and steady rotational speed.
2. Phase: 1-Phase The phase is easy to work with standard electrical systems.
3. Voltage: 240 VAC Works with wide ranges of supplies used on standard power systems.
4. Current: Low Current Draw: 0.2 Amps Low Power consumption for energy-efficient application.
5. Frequency: 50 Hz and 60 Hz. Applicable for many standards for power system in different countries
6.Speed: 60/72 RPM, stable and constant motor speed
7. Connector Part Number: 223489-009, Replaceable and compatible.
8. Country of Origin: Made in the U.S.A., high manufacturing standards and quality control.
9. Weight: Light weight at 1.4 Kg, easy to handle and install.
1. Clocks and Timers: Widely applied in clock mechanisms as well as other timing applications where continuous and accurate rotational speed is necessary.
2. Automation Systems: Applicable in automation and control applications when consistent speed and precise synchronization are necessary.
3. Rotary Equipment: For purposes that involve rotary equipment, such as precise, steady motion of conveyors, small pumps, and fans.
4. Measurement Instruments: For use with metering systems or other instruments where precise rotational speed is paramount.
5. Industrial Control Systems: In the application of control systems, it can be applied wherever uniform speed is needed for ensuring that efficiency and smoothness prevail.
6. Small Appliances: They are mounted on small domestic or industrial appliance requiring stability and synchronized motion for efficient function.
