Terasaki Electric At12 Air Circuit Breaker 1250A Ac480V 65Ka
Terasaki Electric Co., Ltd.
Matsushita
Tempower
Air Circuit Breaker
At12
Poles: 3
Operational Volt. (Ue): 690Vac
Rated Frequency: 50/60 Hz
Rated Curren
| Specification | Details |
|---|---|
| Product Name | Terasaki Electric At12 Air Circuit Breaker 1250A Ac480V 65Ka |
| Manufacturer | Terasaki Electric Co., Ltd. |
| Brand | Matsushita |
| Model | Tempower |
| Type | Air Circuit Breaker |
| Series | At12 |
| Poles | 3 |
| Operational Voltage (Ue) | 690Vac |
| Rated Frequency | 50/60 Hz |
| Rated Current (In) | 1250A |
| Standard | Iec947-2 |
| Utilization Category | B |
| Breaking Capacity (Icu) | 690V, 550-600V 50/50Ka |
| Ics=100% Icu | 220-500V 65/50Ka |
| Short Time Withstand Current (Icw) | 1Sec 50Ka 3Sec 45Ka |
| Part Number | Atps0017-b |
| Model Number | Nk (84T225) At12 |
| Interrupting Capacity | With Installation: Ac480V 65Ka Without Installation: Ac480V 50Ka |
| Ambient Temperature | 45˚C |
| Auxiliary Switch | Axt-1Ab |
| Auxiliary Switch Details | 10P 5A 5B, Rqu2312A1 |
| Over-current Trip | Aor-1Bs-as |
| Base Current Io | 898A |
| CT Rating Icr | 1250/5A |
| S1-SO | Ac/Dc100-~250V |
| SP-SO | Dc 24V |
| Magnet Hold Trigger | Att-1 |
| Additional Switches | Ta-8472-1-1 Axt-1C 2A 2B Btxs0006-a |
| Auxiliary Switch Rating | 16A380V Ac |
| Accessories | Ø0.22 4500T Ø0.32 1700T |
| Closing | Motor Charging (Ac110V) |
| OCR | (Aor-1Bs-as) Io=898A Ict=1250A/5A |
| Tripping | Under Voltage Trip (Ac110V) |
| Switch Details | Aux. Sw 5A5B |
| Manufacture Details | 02103510010 00121-42 Made In Japan |
| Weight | 80 Kg |
At12 Air Circuit Breaker, designed to meet the needs of industrial applications. Manufactured by Terasaki Electric Co., Ltd., a trusted name in electrical components, this Air Circuit Breaker exemplifies advanced technology and safety standards. The Terasaki At12 is manufactured for efficiency and durability, boasting a robust construction that ensures reliable operation even in the most challenging environments. With a rated operational voltage (Ue) of 690Vac and a rated frequency of 50/60 Hz, it offers versatile performance suitable for a wide range of industrial contexts.
Key features of the Terasaki At12 include its impressive rated current (In) of 1250A, making it ideal for handling substantial electrical loads with ease. It operates seamlessly across three poles, ensuring comprehensive protection and efficient distribution of electrical power. This breaker adheres to the IEC947-2 standard, underscoring its compliance with international safety and performance guidelines. Designed with precision and innovation, the Terasaki At12 integrates advanced technologies to deliver superior performance and reliability. Its ability to withstand short-circuit currents up to 65Ka at Ac480V ensures robust protection against electrical faults, safeguarding equipment and personnel from potential hazards. Manufactured to optimize operational efficiency, this Air Circuit Breaker features intuitive controls and indicators for seamless monitoring and management of electrical circuits. Its ergonomic design facilitates easy installation and maintenance, minimizing downtime and enhancing productivity in industrial operations. Ideal for various industrial applications including manufacturing plants, commercial complexes, and infrastructure projects, the Terasaki At12 Air Circuit Breaker stands as a testament to reliability, efficiency, and safety in electrical distribution systems.
The Terasaki At12 Air Circuit Breaker 1250A Ac480V 65Ka represents a peak of manufacturing excellence, combining robust construction, advanced features, and safety standards. Whether you're upgrading an existing electrical system or integrating new equipment, this breaker delivers performance and composure, making it a preferred choice among perceptive professionals in the industrial sector.
Explore the enhanced capabilities of the Terasaki Electric At12 Air Circuit Breaker 50/60Hz , designed to meet the demands of industrial applications with its robust construction and advanced technological features. Operating seamlessly at a rated current (In) of 1250A and a rated operational voltage (Ue) of 690Vac, this breaker ensures reliable performance across three poles, adhering to the IEC947-2 standard for comprehensive safety compliance. Ideal for different industrial applications, it offers efficient protection against short-circuit currents up to 65Ka at Ac480V, ensuring operational reliability and safety in critical electrical distribution systems.
