Abb Alcl-15-5 Filter Module 669A 500V 64735667 Rev.E 64735667E2311064Te 630A
Abb Oy
Trafotek
Electronic Concepts Europe
Type: Alcl-15-5
Trr U 3~ 380…500V
I 630A Ip00 Ul Open Type
F 48…63Hz
Code: 64735667 Rev.E
| Specification | Details |
|---|---|
| Product Name | ABB ALCI-15-5 Filter Module 669A 500V 64735667 Rev.E 64735667E2311064Te 630A |
| Manufacturer | ABB Oy, Trafotek, Electronic Concepts Europe |
| Type | ALCI-15-5 |
| Voltage Range (Trr U) | 3~ 380…500V |
| Current (I) | 630A |
| Protection Type | IP00 UL Open Type |
| Frequency (F) | 48…63Hz |
| Code | 64735667 Rev.E |
| Additional Code | 64735667E2311064Te |
| Other Code | E204394 |
| Calc | 16318 |
| Type | 3Ku180/110 |
| Inductance (L1) | 0.0550 mH |
| Voltage (U) | 500V |
| Alcl-15-5 | L2 |
| Thermal Current (Ith) | 669A |
| Inductance (L2) | 0.0820 mH |
| Additional Codes | 64791745, 68239290 |
| Capacitance (Mp9-20933K) | 3X123μF ±10% |
| Voltage (Mp9-20933K) | 500 Vac/900 Vdc |
| Capacitance Measurement 1 | 185.4 μF, 830 μΩ |
| Capacitance Measurement 2 | 185.3 μF, 825 μΩ |
| Capacitance Measurement 3 | 185.4 μF, 985 μΩ |
| Warning | Avoid Contact With Terminals |
| Additional Code | 68239290B2220000Ece |
| Calc | 16317 |
| Additional Codes | Ar2953, 5061 |
| Country of Manufacture | Estonia |
| Weight | 206 Kg |
The ALCL-15-5 Filter Module (model 669A 500V, part number 64735667 Rev.E) is a high-performance electronic component designed for use in demanding industrial conditions. This filter module is manufactured by ABB Oy, known for its excellence in electrical engineering, and it is also associated with Trafotek and Electronic Concepts Europe. The ALCL-15-5 operates efficiently within a voltage range of 380 to 500V and is rated for a continuous current of 630A. This module is classified under the open type with an IP00 rating, which means it is intended for use in environments where it is protected from direct contact but not necessarily from dust or water. The filter operates at a frequency of 48 to 63Hz, making it versatile for various applications. Its robust design ensures reliability and durability, even in harsh operating conditions. The ALCL-15-5 comes with specific technical codes and designations such as 64735667E2311064Te and E204394, which are critical for its identification and compatibility with other systems. This filter module is meticulously engineered to deliver high efficiency and stability in filtering applications.
The ABB ALCL-15-5 Filter Module is a component with detailed specifications that provide to high-demand applications. The filter module has a total inductance of 0.0550 mH for ALCL-15-5 L1 and 0.0820 mH for ALCL-15-5 L2, with a maximum operating voltage of 500V. It can handle a thermal current (Ith) of up to 669A, ensuring it can manage significant electrical loads. The filter is constructed with high-quality capacitors, including three 123 μF ±10% capacitors rated for 500 Vac/900 Vdc, contributing to its effective filtering performance. The unit is designed to operate at frequencies between 48 and 63 Hz, making it adaptable to various electrical systems. Additionally, the module has precise capacitance values, with measurements of 185.4 μF and resistance values of 830 μΩ, 825 μΩ, and 985 μΩ. It is important to avoid contact with the terminals to ensure safety and prevent damage. Manufactured in Estonia, this filter module weighs 206 kg, reflecting its sturdy build. It is ideal for applications requiring high efficiency and stability in filtering electrical signals.
For another exceptional filtering solution, consider the the ABB ALCL-24-7 Filter Module 64735900. This module shares the same high standards of quality and reliability as the ABB ALCL-15-5, making it an excellent choice for applications requiring robust performance in managing electrical noise and ensuring stable operation in industrial conditions.
