The ABB 64310810 ACS600 Multidrive Module (Type ACW6345145600000300902) is a high-power industrial variable frequency drive module designed for integration into ABB's ACS600 multidrive systems. Manufactured by ABB Oy in Finland, this drive module delivers exceptional motor control performance with an output current rating of 4300A/1156A and output frequency range of 0-300 Hz at up to 600V maximum. For the most demanding industrial automation applications requiring precise, high-power motor control, the ACS600 multidrive module provides the performance, reliability, and flexibility that mission-critical processes demand.

The ABB ACS600 series represents a modular approach to industrial drives, allowing system integrators and end users to configure multi-motor drive systems with a common DC bus architecture that optimizes energy efficiency and reduces equipment footprint. The ACW6345145600000300902 inverter module converts the DC bus voltage to variable-frequency, variable-voltage AC power for motor control, while the companion ACW6441390600000300900 rectifier section (Code 64277456) provides the DC bus from the AC supply. The NGDR-03C gate driver and NXPP-03C control modules complete the drive's internal architecture, delivering the switching performance and control accuracy that distinguish ABB drives from competitors.

Key Features & Specifications

The ABB 64310810 ACS600 multidrive module incorporates ABB's most advanced drive technology, including Direct Torque Control (DTC) for precise motor control without encoder feedback in most applications. The modular design provides exceptional flexibility for system configuration and future expansion.

• Output Current (I2n): 4300A/1156A for high-power motor control
• Output Frequency: 0-300 Hz wide speed range
• Maximum Voltage: 600V for industrial power systems
• Output Voltage: 3-phase 0 to U1 V (follows input)
• Module Type: ACW6345145600000300902 (Inverter)
• Product Code: 64310810
• Companion Rectifier: ACW6441390600000300900 (Code 64277456)
• Gate Driver: NGDR-03C (Code 64008544C)
• Control Module: NXPP-03C
• Manufacturer: ABB Oy, Made in Finland
• Weight: 58 kg

Technical Specifications

Specification	Details
Product Code	64310810
Module Type	ACW6345145600000300902
Product Series	ABB ACS600 Multidrive
Manufacturer	ABB Oy, Finland
Output Current (I2n)	4300A / 1156A
Output Frequency Range	0 - 300 Hz
Maximum Voltage	600V
Output Configuration	3-Phase 0 to U1 V
Companion Rectifier Type	ACW6441390600000300900
Companion Rectifier Code	64277456
Gate Driver Module	NGDR-03C (Code 61353364D)
Control Module	NXPP-03C
Weight	58 kg

Applications & Use Cases

The ABB 64310810 ACS600 multidrive module is engineered for the most demanding industrial automation applications where high-power motor control is essential. The 4300A/1156A current rating makes this module suitable for very large motors in metal rolling mills, mine hoists, large extruders, pulp and paper machine drives, and test stand applications. The 0-300 Hz frequency range accommodates both standard 50/60Hz motors and high-speed applications where extended speed ranges are required.

The ACS600 multidrive architecture is particularly well-suited for coordinated multi-axis systems where multiple motors operate from a common DC bus. This configuration allows energy to flow between motors during regenerative braking, dramatically reducing overall energy consumption compared to systems where each drive operates independently from the AC line. Applications include processing lines with multiple driven sections, test stands with dynamometer loading, and marine propulsion systems where the common DC bus simplifies system architecture and improves overall efficiency. The 600V maximum rating suits medium-voltage industrial distribution systems where voltage boost is not required.

Why Choose the ABB ACS600 Multidrive Module

ABB's ACS600 series has earned a reputation as one of the most capable and reliable industrial drive platforms ever developed. The Direct Torque Control (DTC) technology provides motor control performance that approaches servo quality without requiring encoder feedback for most applications. This translates to precise speed and torque regulation, rapid dynamic response to load changes, and smooth low-speed operation that competing drives struggle to match. The modular architecture simplifies maintenance by allowing individual modules to be replaced without disturbing the entire system, reducing Mean Time To Repair (MTTR) and improving overall system availability.

The Finnish manufacturing heritage of this module reflects ABB's commitment to quality in its high-power drive products. The 58 kg construction demonstrates the substantial engineering that goes into a drive module capable of reliably delivering thousands of amps of controlled current. The companion rectifier (ACW6441390600000300900 / Code 64277456) and inverter module (ACW6345145600000300902 / Code 64310810) combination represents a matched set designed to work together for optimal performance. When you purchase from Auto2mation, you receive our 30-day warranty, free shipping, and the support of a team that understands the critical nature of high-power industrial drive applications.

Compatibility & Integration

The ABB 64310810 ACS600 multidrive module is designed for integration into ACS600 multidrive systems as part of a coordinated drive lineup. The module connects to the common DC bus and receives control signals from the master control unit. The NGDR-03C gate driver and NXPP-03C control module manage the power semiconductor switching and communication functions, ensuring precise coordination with other drive modules in the system.

Integration into existing ACS600 systems requires verification of compatibility with the existing control system version and DC bus configuration. The ACW6345145600000300902 inverter module is designed to work with the ACW6441390600000300900 rectifier module (Code 64277456) for a complete drive solution. Auto2mation can provide guidance on system integration questions, compatibility verification, and documentation to support successful deployment. For facilities with existing ACS600 installations, this module can serve as a replacement for a failed unit or as part of a system expansion project.

Maintenance & Support

The ABB ACS600 series is designed for long, reliable service life in demanding industrial environments. The modular architecture simplifies troubleshooting and maintenance by allowing individual functional modules to be tested and replaced independently. The drive's comprehensive self-diagnostics monitor power semiconductor health, cooling system performance, control circuit integrity, and communication link status, generating alarms before failures occur to enable predictive maintenance scheduling.

Auto2mation provides knowledgeable support for all ABB drives we supply. Our team includes professionals experienced in high-power industrial drives, multidrive systems, and industrial automation applications. We can assist with integration guidance, troubleshooting support, and coordination with ABB's service network for factory-authorized repairs and recertification. Our 30-day warranty and free shipping provide confidence in your purchase of this high-value industrial equipment.

Frequently Asked Questions

Q1: What motor power can this drive module control?

With a 4300A/1156A rating, this module can control very large motors up to several megawatts depending on voltage and duty. The exact motor size depends on the application requirements including torque, speed range, and duty cycle. Contact Auto2mation for application-specific sizing assistance.

Q2: Is this a complete drive or just an inverter module?

This is an inverter module (ACW6345145600000300902) designed for use in an ACS600 multidrive system with a common DC bus. It requires a rectifier unit (ACW6441390600000300900 / Code 64277456) to provide the DC bus voltage from the AC supply.

Q3: What is Direct Torque Control (DTC) technology?

DTC is ABB's proprietary motor control algorithm that directly controls motor torque and flux without requiring modulation. This provides superior dynamic performance, precise torque control, and smooth low-speed operation that approaches servo quality without encoder feedback in most applications.

Q4: Can this module be used as a replacement in an existing ACS600 system?

Yes, this module is designed as a replacement or expansion component for existing ACS600 multidrive installations. Compatibility with the existing control system version and DC bus configuration should be verified before installation. Auto2mation can assist with compatibility questions.

Q5: What warranty and shipping does Auto2mation provide?

Auto2mation provides a 30-day warranty on all used products covering defects in materials and workmanship. All orders include free worldwide shipping with secure industrial packaging appropriate for high-value electronic equipment.
