The ABB ACS800-104-0580-7+C126+E205+V991 Inverter Drive Module (Code: 68685745) represents the apex of ABB's industrial drive technology, designed for the most demanding high-power motor control applications in industrial automation, marine propulsion, and heavy process industries. This modular inverter unit from ABB's acclaimed ACS800 series is capable of delivering 486A at output voltages up to 690V AC, with an input DC bus range of 709-976 VDC. The comprehensive option configuration, including the C126, E205, and V991 modules, provides enhanced functionality for system integration, extended I/O, and specialized control applications.

Large-scale industrial operations, marine engineering firms, and power generation facilities worldwide specify ABB ACS800 series drives for their exceptional performance in the most challenging motor control applications. The 104-0580-7 inverter module is engineered for multi-megawatt drive systems where the modular architecture enables flexible system configuration, redundant capacity, and simplified maintenance. Whether controlling large pump motors in water treatment facilities, propulsion motors in marine vessels, or process drives in mining and metals processing, this ABB inverter module delivers the precision, power, and reliability that critical applications demand.

At Auto2mation, we specialize in sourcing and supplying high-power industrial automation equipment from the world's leading manufacturers. Every ABB ACS800 module in our inventory undergoes thorough testing and quality verification, and we provide our industry-leading 30-day warranty along with free worldwide shipping to ensure your project receives the critical drive components it needs on schedule.

Key Features & Specifications

The ABB ACS800-104-0580-7 inverter module incorporates ABB's proprietary Direct Torque Control (DTC) technology, which provides exceptional dynamic response and torque accuracy without requiring motor speed feedback in most applications. The modular design philosophy of the ACS800 series enables system integrators to configure drive systems with precisely the right combination of power modules, option boards, and accessories for each application. The C126, E205, and V991 option modules extend the base drive capability with additional communication interfaces, expanded I/O capacity, and specialized control functions.

• Part Number: ACS800-104-0580-7+C126+E205+V991
• Code: 68685745
• Inverter Input: 709-976 VDC, 583A DC
• Inverter Output: 3-phase 0-690V AC, 486A, 0-300 Hz
• Line Converter Input: 3-phase 525-690V AC, 400A
• Control Technology: ABB Direct Torque Control (DTC)
• Option C126: Extended I/O capability module
• Option E205: Enhanced control functionality
• Option V991: Specialized application module
• Cooling Fan: EBM-Papst D2D160-CE02-11, 230/400V
• Enclosure: IP00 chassis for cabinet installation
• Manufacturer: ABB Oy Drives

Technical Specifications

Specification	Details
Manufacturer	ABB Oy Drives
Product Series	ACS800 MultiDrive
Part Number	ACS800-104-0580-7+C126+E205+V991
Product Code	68685745
Inverter DC Input	709-976 VDC (848V UL/CSA), 583A DC
Inverter AC Output	3-phase 0-690V (600V UL/CSA), 486A
Output Frequency	0 to 300 Hz
Line Converter Input	3-phase 525-690V AC (600V UL/CSA), 400A
Control Method	Direct Torque Control (DTC)
Options	C126, E205, V991
Cooling Fan	EBM-Papst D2D160-CE02-11
Fan Voltage	230/400V AC, 50/60 Hz
Enclosure	IP00 (Chassis)
Typical Motor Power	Approximately 450-560 kW at 690V

Applications & Use Cases

The ABB ACS800-104-0580-7 inverter module is engineered for the upper echelon of industrial motor control applications where power requirements exceed the capabilities of standard enclosed drives. Its modular architecture, high voltage capability, and exceptional current rating make it the drive of choice for system integrators and OEMs building custom drive solutions for the most demanding industries.

Large Pump & Compressor Systems

Municipal water treatment plants, oil and gas pipeline systems, and mining dewatering operations utilize large centrifugal pumps driven by motors in the 400-600 kW range. The ABB ACS800-104-0580-7 provides the precise speed control needed to optimize pump performance for varying system demand, delivering substantial energy savings compared to throttling valve control. The Direct Torque Control algorithm maintains stable pump operation across the entire speed range, eliminating the surge and cavitation issues that can damage expensive pumping equipment.

Marine Propulsion & Thruster Systems

Electric propulsion systems on ferries, offshore supply vessels, and specialized marine craft require high-power drives capable of delivering precise torque control for main propulsion motors and azimuth thrusters. The ACS800 series is widely deployed in marine electric propulsion systems, where the modular architecture enables redundant configurations that maintain partial propulsion capability even in the event of a single module failure. The 690V output capability matches standard marine medium-voltage distribution systems, minimizing transformer requirements.

Mining & Minerals Processing

The mining industry demands motor control equipment capable of operating in harsh environments with extreme dust, vibration, and temperature conditions. The ABB ACS800-104-0580-7 drives large mills, crushers, conveyors, and hoists in mineral processing plants, providing the high starting torque and overload capacity needed for these demanding applications. The IP00 chassis format allows installation in custom-built mine-duty enclosures with enhanced filtration and cooling systems designed for the specific environmental conditions of each installation.

Power Generation & Utilities

Power plants and utility operations utilize high-power variable frequency drives for boiler feed pumps, induced and forced draft fans, cooling water pumps, and circulating water systems. The ABB ACS800-104-0580-7 meets the stringent reliability requirements of power generation applications, where unplanned downtime can have significant economic and operational consequences. The modular architecture facilitates rapid module replacement during scheduled maintenance windows, minimizing outage duration.

Why Choose the ABB ACS800-104-0580-7 Inverter Module

The ABB ACS800 series has established the benchmark for high-power industrial drives through its innovative modular architecture and industry-leading Direct Torque Control technology. When evaluating drive solutions for the most demanding motor control applications, engineering professionals consistently select the ACS800 series for its unique combination of performance, flexibility, and reliability.

Direct Torque Control Technology

ABB's patented Direct Torque Control (DTC) technology provides dynamic speed and torque response that exceeds the performance of traditional PWM vector control drives. DTC directly controls motor flux and torque without requiring modulator stages or motor speed feedback in most applications, resulting in torque response times as fast as 1-2 milliseconds. This exceptional dynamic performance enables precise speed regulation even under rapidly varying load conditions, and provides full torque at zero speed for crane and hoist applications.

Modular System Architecture

The ACS800 series modular design separates the power conversion, control, and cooling functions into interchangeable modules that can be configured to match specific application requirements. This modularity enables system designers to build custom drive solutions with the precise combination of power rating, I/O capability, and communication interfaces needed for each project. In the event of a component failure, individual modules can be replaced without removing the entire drive, significantly reducing mean time to repair (MTTR).

Enhanced Option Configuration

The C126, E205, and V991 option modules on this particular ACS800-104-0580-7 provide extended functionality beyond the base drive capability. The C126 module expands analog and digital I/O capacity for complex control schemes, the E205 module adds enhanced control functions for specialized applications, and the V991 module provides application-specific software extensions. This comprehensive option configuration maximizes the drive's integration flexibility while minimizing the need for external control components.

Compatibility & Integration

The ABB ACS800-104-0580-7 is designed for integration into custom-built drive systems by OEMs and system integrators. Its IP00 chassis format requires installation within an appropriate electrical enclosure with adequate cooling and environmental protection for the specific application.

DC Bus System Integration

The ACS800-104 series inverter modules are designed to operate from a common DC bus, which is supplied by an ACS800 line converter module or active rectifier. The inverter input accepts DC voltages from 709-976 VDC, corresponding to AC line voltages of 525-690V through the rectification process. Multiple inverter modules can share a common DC bus in multi-axis drive systems, enabling energy exchange between motoring and regenerating axes for improved overall system efficiency.

Motor Compatibility

The ACS800-104-0580-7 is compatible with standard AC induction motors and ABB synchronous motors rated for inverter duty operation at voltages up to 690V AC. At its 486A current rating, this module is suitable for motors in the approximately 450-560 kW range at 690V. ABB's DTC technology automatically adapts to the specific motor characteristics during the commissioning process, optimizing control performance without requiring extensive motor parameter knowledge.

Communication & Control Interfaces

The ACS800 series supports all major industrial communication protocols including Profibus DP, DeviceNet, CANopen, Modbus RTU, and Ethernet/IP through optional fieldbus adapter modules. The enhanced I/O provided by the C126 option module extends the base analog and digital I/O capability, enabling direct connection of sensors, actuators, and control signals without requiring external I/O modules. The DriveWindow PC-based commissioning software provides comprehensive drive configuration, monitoring, and diagnostic capabilities.

Maintenance & Support

The modular architecture of the ACS800 series significantly simplifies maintenance procedures and reduces downtime in the event of component failure. ABB's comprehensive diagnostic capabilities enable proactive maintenance scheduling and rapid fault identification.

Preventive Maintenance

Quarterly maintenance should include inspection of cooling fans and air filters, verification of DC link voltage, and checking for abnormal temperatures or noises. Annual maintenance includes torque verification of power connections, cleaning of heat sinks, and inspection of DC link capacitors. The modular design allows individual components such as fans, capacitors, and control boards to be replaced without removing the entire drive module from service.

Warranty & Service

Auto2mation provides a comprehensive 30-day warranty on the used ABB ACS800-104-0580-7 inverter module, covering all functional aspects of the unit. Our technical support team can assist with integration guidance, commissioning procedures, and troubleshooting throughout the warranty period. Free worldwide shipping ensures timely delivery to any project location.

Frequently Asked Questions

Q1: What is the power rating of the ABB ACS800-104-0580-7?

The ABB ACS800-104-0580-7 inverter module delivers 486A at output voltages up to 690V AC, corresponding to approximately 450-560 kW of motor power depending on the specific motor efficiency and power factor. The actual motor power rating also depends on the duty cycle, overload requirements, and ambient temperature conditions of the application.

Q2: What do the C126, E205, and V991 options provide?

The C126 option module extends the drive's analog and digital I/O capacity for complex control schemes requiring additional sensor inputs and control outputs. The E205 module adds enhanced control functions and software capabilities beyond the base drive configuration. The V991 module provides specialized application software extensions for specific industry requirements. Together, these options maximize the drive's flexibility for integration into sophisticated automation systems.

Q3: What is Direct Torque Control (DTC) technology?

Direct Torque Control is ABB's patented motor control algorithm that directly controls motor flux and electromagnetic torque without requiring a separate modulator or motor speed feedback encoder in most applications. DTC provides torque response times of approximately 1-2 milliseconds, which is significantly faster than traditional vector control methods. This exceptional dynamic performance enables precise speed regulation under rapidly varying loads and provides full torque at zero speed.

Q4: What input power does this drive module require?

The ACS800-104-0580-7 is an inverter module that requires a DC bus input of 709-976 VDC. This DC voltage is typically supplied by an ACS800 line converter module (active rectifier) connected to a 525-690V AC, 3-phase power supply. The line converter input accepts 400A at voltages of 525-690V AC. System integrators must ensure that the rectifier and DC bus components are properly sized for the specific application requirements.

Q5: What enclosure is required for this IP00 module?

The ACS800-104-0580-7 is supplied as an IP00 chassis module and must be installed within a custom-built electrical enclosure that provides the appropriate level of environmental protection, cooling airflow, and safety interlocks for the specific application. ABB provides detailed enclosure design guidelines covering ventilation requirements, clearances, and thermal management. Auto2mation can provide application guidance for proper enclosure specification.

Q6: What warranty does Auto2mation provide?

Auto2mation provides a comprehensive 30-day warranty on this used ABB ACS800-104-0580-7 inverter drive module, covering all functional aspects of the power section, control electronics, and option modules. Free worldwide shipping is included with every purchase, and our technical support team is available to assist with integration guidance and troubleshooting throughout the warranty period.
