The ABB ACS800-704LC-2150-7 IP00 Drive Supply Unit is a high-capacity industrial power conversion module that forms the backbone of large-scale ACS800 multi-drive systems. Manufactured by ABB Oy in Finland under code 68648858, this open-type (IP00) drive supply unit is engineered to convert three-phase AC line power into a regulated DC bus, delivering the massive power capacity required by the most demanding industrial automation and marine technology applications.

With a formidable AC input current capacity of 1796 amps and the ability to deliver 2200 Adc on the DC output bus, this drive supply unit is built for facilities where multiple high-power motors need to be controlled simultaneously from a common DC bus architecture. The IP00 open construction allows system integrators to design custom enclosures tailored to specific environmental requirements while maximizing thermal performance and simplifying maintenance procedures.

Auto2mation offers this used ABB drive supply unit with complete confidence, backed by our comprehensive 30-day warranty, free worldwide shipping, and dedicated technical support. Our thorough inspection and testing process ensures that every unit we sell delivers reliable performance in your critical application.

Key Features & Specifications

The ABB ACS800-704LC-2150-7 IP00 drive supply unit incorporates advanced power electronics technology and robust construction features that have made the ACS800 series the industry benchmark for heavy-duty motor control. Here are the standout characteristics of this industrial power module:

• Massive Power Capacity: AC input rated for 1796 amps at 380 to 690 VAC three-phase, with DC output capability of 2200 Adc at 513 to 932 VDC, supporting the largest multi-drive configurations.
• IP00 Open Type Design: The open chassis construction provides unrestricted airflow for optimal cooling of power semiconductors and allows direct access for maintenance, testing, and troubleshooting without enclosure disassembly.
• Active Front-End Converter: Integrated active line converter provides near-unity power factor, low total harmonic distortion, and four-quadrant operation for energy recovery during regenerative braking.
• DSMB-03C Control System: Revision F of the DSMB-03C control board provides comprehensive monitoring, fault protection, and communication capabilities for integration with modern automation systems.
• UL Listed Construction: Meets UL open type standards for safety and reliability, with 600V UL and CSA ratings on both AC input and DC output circuits.
• Finnish Manufacturing Quality: Produced by ABB Oy in Finland to exacting European quality standards, ensuring long-term reliability in the most demanding industrial environments.

Technical Specifications

Specification	Details
ABB Code	68648858
Part Number	ACS800-704LC-2150-7 IP00
Manufacturer	ABB Oy, Finland
Condition	Used / Refurbished
AC Input Voltage	3-Phase 380 to 690 VAC (600V UL/CSA)
AC Input Current	1796 A
Input Frequency	48 to 63 Hz
DC Output Voltage	513 to 932 VDC (810V UL/CSA)
DC Output Current	2200 Adc
Enclosure Type	IP00, UL Open Type
Control Board	DSMB-03C, Rev. F
Weight	195 Kg

Applications & Use Cases

The ABB ACS800-704LC-2150-7 IP00 drive supply unit serves as the power backbone for the most demanding industrial automation systems where high-capacity DC bus power is required. Its applications span across multiple heavy industries:

Large-Scale Manufacturing Plants

Automotive assembly lines, steel mills, cement plants, and paper mills utilize common DC bus architectures where a single drive supply unit feeds dozens of inverter modules controlling motors throughout the production process. The 2200 Adc output capacity supports these extensive multi-drive configurations while the active front-end technology minimizes harmonic impact on the facility electrical system.

Electric Marine Propulsion

Commercial vessels with electric propulsion systems, including offshore supply vessels, ferries, and icebreakers, rely on high-capacity drive supply units to convert generator power to DC bus voltage for propulsion inverters. The IP00 construction allows marine system integrators to design custom enclosures that meet classification society requirements for shipboard electrical equipment.

Mining and Mineral Processing

Mine hoist systems, conveyor belts, crushers, grinding mills, and slurry pumps in mining operations require rugged motor control equipment capable of operating in dusty, high-vibration environments. The open-type design facilitates the custom protective enclosures needed for these harsh conditions while providing the high power capacity essential for large mining equipment.

Renewable Energy Systems

pumped-storage hydroelectric facilities, tidal power installations, and energy storage systems use bidirectional power converters based on the ACS800 drive supply architecture. The four-quadrant capability of the active front-end allows power flow in both directions, essential for energy storage charge and discharge cycles.

Test Benches and Research Facilities

Automotive test cells, aerospace propulsion test facilities, and industrial research laboratories require precision-controlled dynamometer systems capable of absorbing and regenerating large amounts of power. The ACS800-704LC-2150-7 provides the DC bus infrastructure for these high-performance test systems.

Why Choose This ABB Drive Supply Unit

Selecting a used drive supply unit from Auto2mation offers compelling advantages for budget-conscious projects and maintenance replacements:

Significant Capital Savings

New drive supply units of this capacity represent a major capital expenditure with extended lead times from the manufacturer. Sourcing a tested used unit from Auto2mation typically delivers cost savings of 50 to 70 percent while providing equipment that meets the same performance specifications as new units.

Immediate Availability

Manufacturing lead times for new high-capacity drive equipment can extend to 20 weeks or more. Our used inventory provides immediate availability for emergency replacements, project acceleration, or opportunistic capacity expansions where delivery speed is critical.

Proven Operational Track Record

The ACS800 platform has demonstrated exceptional reliability across millions of operating hours in industrial applications worldwide. A properly maintained used unit from this proven product family offers reliability that often exceeds that of newly introduced products that have not yet accumulated equivalent field experience.

Compatibility & Integration

Successful integration of the ACS800-704LC-2150-7 IP00 requires careful attention to electrical, mechanical, and environmental compatibility factors:

• AC Power Infrastructure: Verify that upstream transformers, switchgear, and cabling are rated for 1796A continuous current at 380 to 690 VAC. Coordination with utility service limits may be necessary for installations of this scale.
• DC Bus Architecture: The 513 to 932 VDC output is compatible with all ACS800-104, ACS800-204, and related inverter module families. The DC bus must be designed to safely carry 2200 Adc continuous current with appropriate protection devices.
• Custom Enclosure Design: The IP00 rating requires the system integrator to provide appropriate enclosure, ventilation, and environmental protection. Enclosure design must consider heat dissipation requirements, accessibility for maintenance, and applicable safety standards.
• Control System Interface: The DSMB-03C control board interfaces with ABB's drive control system through fiber optic communication links. Verify software version compatibility with existing control hardware in retrofit applications.
• Mechanical Support: At 195 Kg, this unit requires a structurally adequate mounting surface with provisions for lifting and handling during installation and maintenance activities.

Maintenance & Support

Auto2mation stands behind every product we sell with comprehensive warranty coverage and technical support services. When you purchase this ABB ACS800-704LC-2150-7 IP00 drive supply unit, you receive more than just equipment, you gain a committed partner in your industrial automation success.

Our standard 30-day warranty covers defects in materials and workmanship, giving you confidence in your purchase decision. Our free worldwide shipping includes professional export packaging designed to protect this heavy industrial equipment during international transit.

For ongoing maintenance, we recommend working with ABB's authorized service network for factory repairs, spare parts, and software updates. Preventive maintenance should include periodic inspection of power connections, cooling system verification, filter replacement, and control board battery replacement at recommended intervals.

Frequently Asked Questions

Q1: What does IP00 rating mean for this drive supply unit?

IP00 indicates that the unit has no ingress protection against solid objects or liquids. It must be installed in a suitable electrical enclosure or equipment room that provides protection against accidental contact, dust, moisture, and foreign objects. The open design provides unrestricted airflow for optimal cooling.

Q2: What is the difference between this IP00 unit and an enclosed version?

The IP00 open-type unit requires the user to provide external enclosure and environmental protection. This provides flexibility for custom installations but requires additional engineering. Enclosed versions include a factory-designed enclosure but at higher cost and with less installation flexibility.

Q3: How many inverter modules can this supply unit support?

The number of inverter modules depends on their individual power ratings and duty cycles. With 2200 Adc continuous output capacity, this unit can typically support 4 to 8 high-power inverter modules or a larger number of smaller modules, provided that the total DC load does not exceed the supply unit rating.

Q4: Is this unit suitable for regenerative applications?

Yes, the active front-end converter supports four-quadrant operation, allowing energy to flow from the DC bus back to the AC line during regenerative braking. This capability makes the unit suitable for applications with frequent deceleration of high-inertia loads.

Q5: What testing has been performed on this used unit?

Auto2mation performs visual inspection, electrical connection testing, insulation resistance testing, and functional verification on all used drive supply units before shipment. A certificate of inspection is provided with each unit documenting the testing performed.

Q6: What warranty and support does Auto2mation provide?

We provide a 30-day warranty covering defects in materials and workmanship, free worldwide shipping with professional packaging, and technical support for installation and commissioning. Our customer service team is available to answer questions and provide application guidance.
