Gm International D1063S Strain Gauge Bridge Isolating Repeater 20 To 30Vdc
Made By G.M. International S.R.L.
D1063S
Strain Gauge Bridge
Isolating Repeater
Supply: 20 To 30Vdc,
Max Power: 2.8W
Ii (1) G D [Eex Ia] Iic
Gm International D1063S Strain Gauge Bridge Isolating Repeater 20 To 30Vdc
Made By G.M. International S.R.L.
D1063S
Strain Gauge Bridge
Isolating Repeater
Supply: 20 To 30Vdc,
Max Power: 2.8W
Ii (1) G D [Eex Ia] Iic
Dnv-2004-osl-atex-0199
Uo= 17.3V
Io= 199.6Ma
Po= 864Mw
Co= 351Nf
Lo= 0.8Mh
Lo/Ro=41.2Uh/Ω
At Terminals 9-10-11-12-13-14.
Io= 8Ma
Po= 35Mw
Co= 353Nf
Lo= 300Mh
Lo/Ro= 1020Uh/Ω
Ui= 30V
Ci= 0Nf
Li= 0Nh
At Terminals 13-14
Um: 250V
Tamb: -20 To +60°C
Cl I,Div 1,Gp A, B, C, D;
Cl Ii,Div 1,Gp E, F, G;
Cl Iii,Div 1;
Cl I, Zn 0,Aex [Ia] Iic; Cl I,Zn 0,Ex [Ia] Iic
Iecex
Dnv 07.0001
[Ex Ia] Iic
Ita20769-el001
[Exia] Iic X
I (M2) [Eex Ia] I
Dnv-2004-osl-atex-0199
Ii 3G Ex Na Ii T4
Imq 09 Atex 013 X
Made In Italy
Weight: 150 Gm
