Hyundai Hat06 3 Pole Air Circuit Breaker 690Vac 630Amp
Hyundai Heavy Industries Co., Ltd.
Air Circuit Breaker
Hat06
Poles: 3P
Operational V
| Specification | Details |
|---|---|
| Product Name | Hyundai HAT06 3 Pole Air Circuit Breaker 690Vac 630Amp |
| Manufacturer | Hyundai Heavy Industries Co., Ltd. |
| Type | Air Circuit Breaker |
| Model | HAT06 |
| Poles | 3P |
| Operational Voltage (Ue) | 690V AC |
| Rated Frequency | 50/60 Hz |
| Rated Current | 630 A |
| Standards | IEC 60947-2, ANSI C37.13, EN 60947-2, VDE 0660 |
| Draw-out Type | 630Af |
| Motor Charge | AC 220V |
| CT Rating | 630/5A |
| Io | 326 |
| UVT (Delay) | AC 200-240V |
| Over-current Trip | AOR-1S-AS |
| Base Current (Io) | 326 A |
| CT Rating (Icr) | 630/5A |
| Rated Frequency (Freq.) | 50/60 Hz |
| DC Voltage | 24V |
| AC/DC Voltage Range | 100-250V |
| Charge Up Switch | HATS-CS |
| UVT Trip Device Type | HAST-T |
| UVT Trip Device Voltage | 200V-240V |
| Auxiliary Switch Type | 5A 5B |
| Origin | Made In Korea |
| Weight | 77.500 kg |
The Hyundai HAT06 3 Pole Air Circuit Breaker, manufactured by Hyundai Heavy Industries Co., Ltd. This advanced breaker is designed to meet the requirements of industrial and commercial electrical systems, offering essentials features and exceptional durability. The Hyundai HAT06 operates at a voltage (Ue) of 690V AC and a rated frequency of 50/60 Hz, making it suitable for a wide range of high-voltage applications. With a rated current of 630A, it ensures efficient power distribution and protection against electrical overloads. Compliant with international standards including IEC 60947-2, ANSI C37.13, EN 60947-2, and VDE 0660, the HAT06 guarantees reliability and safety in various operational conditions. Designed as a draw-out type with a 630AF rating, the HAT06 facilitates easy maintenance and swift replacement, minimizing downtime during critical operations. It features a motor charge capability at AC220V, ensuring quick response times for fault conditions and enhancing operational efficiency.
Key Features of HAT06 3 Pole Air Circuit Breaker
Equipped with over-current trip protection (AOR-1S-AS), the HAT06 delivers robust safeguarding against electrical faults, preventing damage to equipment and ensuring personnel safety. Its base current (Io) of 326A and CT rating ICR of 630/5A ensure consistent performance under varying load conditions, making it ideal for applications requiring reliable power distribution and protection. The HAT06 includes a UVT (Under Voltage Trip) device with a delay function, operating at AC 200-240V, enhancing its responsiveness to voltage fluctuations and ensuring reliable operation in fluctuating power conditions. It supports both DC 24V and AC/DC 100-250V inputs, offering versatility in power supply compatibility and optimizing installation flexibility across different electrical systems.
Applications
The Hyundai HAT06 is customized for crucial applications in industries such as manufacturing plants, commercial facilities, and infrastructure projects where reliable power distribution and protection are vital. Its robust design and adherence to international standards make it suitable for:
1.Industrial Facilities: Used in durable industrial conditions where continuous operation and protection against electrical faults are critical.
2.Commercial Buildings: Ensures reliable power distribution and safety in office complexes, shopping malls, and retail outlets.
3.Infrastructure Projects: Supports infrastructure developments including power generation plants, transportation networks, and utilities where dependable electrical systems are essential.
Featuring auxiliary switches (Type 5A, 5B) and UVT trip devices (Type HAST-T) operating at voltages ranging from 200V to 240V, the HAT06 enables comprehensive control and monitoring capabilities. These features enhance system integration and facilitate remote monitoring, ensuring proactive maintenance and operational efficiency. Selecting the Hyundai HAT06 3 Pole Air Circuit Breaker means choosing superior performance, reliability, and safety for your electrical infrastructure. Whether you operate in industrial, commercial, or infrastructure sectors, the HAT06 offers better protection and efficiency. Experience the difference in quality and reliability that sets the HAT06 apart.
