Hyundai Uan32B3A M2C2S268P 3 Pole Air Circuit Breaker 3200A 1000V 50/60Hz
Hyundai Heavy Industries Co., Ltd.
Electro Electric Systems
Air Circuit Breaker
Acb
Uan
Uan32B3A M2C2S268P
| Specification | Details |
|---|---|
| Product Name | Hyundai Uan32B3A M2C2S268P 3 Pole Air Circuit Breaker 3200A 1000V 50/60Hz |
| Manufacturer | Hyundai Heavy Industries Co., Ltd. |
| Division | Electro Electric Systems |
| Type | Air Circuit Breaker (ACB) |
| Model | Uan, Uan32B3A M2C2S268P, Abaeafamaqb6B8Rtv4 |
| Current Rating (In Max) | 3200A |
| Poles | 3 Poles (3200 Af) |
| Ics | 100% Icu |
| Uimp | 12kV |
| Ui | 1000V |
| Frequency | 50/60Hz |
| Standards | EN/IEC 60947-2, VDE 0660/Cat.B, Gost R 50030.2-99 9 / 1-2000 |
| Ue | 550~690V (Icu: 85kA), 220~500V (Icu: 100kA) |
| Icw | 85kA/1s |
| Certification | KSC 4620, No: 09-0140 KSA |
| Ambient Temperature | 45°C |
| Frame | Uan32/B Frame |
| Motor Charge/Closing Voltage/Trip Voltage | A/DC 220V |
| Part Number | A616-04725 |
| Type | Upr SA, Uan323B |
| Code | 3223001205 |
| Production Date | [Dy] 20160630-300 |
| Component Names and Codes | Uans-c2/S02 (Code: 5832000251), Uans-cj-5A5B (Code: 3223-0015-81), U Dr Device-2 (Code: 3223002502) |
| Control Voltage | CC: ADC 200~250 |
| Undervoltage Trip (Uvt) | AC 440 |
| Trip Coil (Tc) | ADC 200~250 |
| Position Switch Type | Uans As, Dunrt Hat 323 Av |
| Model Name | Uans-m2 (Ians-m2) |
| Control Voltage | ADC 220V |
| Software Version | Nmcu V01.03-16050667 |
| Country of Manufacture | Made in Korea |
| Weight | 96 Kg |
The Uan32B3A M2C2S268P 3 Pole Air Circuit Breaker is a top-tier solution designed for high-demand electrical systems. With a remarkable current capacity of 3200A and voltage ratings up to 1000V, this circuit breaker is manufactured to handle large electrical loads, making it ideal for industrial and commercial applications. Its compatibility with both 50Hz and 60Hz systems ensures versatility across different power networks, allowing seamless integration into various setups. The 3-pole design (3200 Af) offers robust protection for three-phase systems, ensuring consistent and reliable performance. Moreover, the breaker adheres to top international standards such as En/Iec 60947-2, Vde 0660/Cat.B, and Gost R 50030.2-99 9 / 1-2000, attesting to its quality, safety, and durability.
One of the standout features of the Hyundai Uan32B3A M2C2S268P is its breaking capacity, rated at Ics = 100% Icu, which signifies its ability to handle fault conditions up to its maximum breaking capacity without degradation. This ensures that the breaker can safely interrupt fault currents of up to 85 kA (Icu), providing unparalleled protection for electrical circuits. The unit also boasts a high impulse withstand voltage (Uimp) of 12kV, which enhances its resilience against transient over voltages often caused by lightning strikes or switching surges. With an operational voltage range (Ue) of 550~690V, this breaker is suitable for a wide array of voltage systems, further broadening its applicability.
Durability and reliability are at the core of the Hyundai Uan32B3A M2C2S268P design. Its construction ensures long-lasting performance even in the most demanding environments. It is designed to comply with rigorous industry standards, ensuring it meets and exceeds the operational safety and efficiency requirements. The Hyundai Uan32B3A M2C2S268P provides a dependable solution for protecting electrical systems from overloads, short circuits, and other electrical faults. Its advanced features and compliance with global standards make it a reliable and efficient choice for professionals seeking high-performance circuit breakers.
For robust performance and reliability in demanding industrial applications, consider this product, the Hyundai Hian 08 Air Circuit Breaker 3 Pole 800A 1000V . Complementing the high-capacity features of the Hyundai Uan32B3A M2C2S268P 3 Pole Air Circuit Breaker 3200A 1000V 50/60Hz, this circuit breaker ensures optimal protection and efficiency for various electrical systems.
