Merlin Gerin M10 N1 Air Circuit Breaker 69 03 5 1 B 1000V Ac 1000A
Merlin Gerin
Masterpact
M10 N1
Ui: 1000V~ 50/60Hz
Ue: 380/440V 480/690V
Icu/Ics: 40Ka 40Ka
Icw: 40Ka 0,5S
| Specification | Details |
|---|---|
| Product Name | Merlin Gerin M10 N1 Air Circuit Breaker 69 03 5 1 B 1000V Ac 1000A |
| Model | 69 03 5 1 B |
| Voltage Rating (Ui) | 1000V AC (50/60Hz) |
| Nominal Voltage (Ue) | 380/440V, 480/690V |
| Breaking Capacity (Icu/Ics) | 40kA / 40kA |
| Short-Circuit Protection (Icw) | 40kA (0.5s) |
| Standard | IEC 947-2 |
| Str Rating | 58 U |
| Nominal Current (In) | 1000A |
| Series/Seris | Tv1656 100 02 |
| Type | 69 03 5 1 B |
| Category | B |
| In (Current Rating) | 3X1000A |
| Shunt Trip | Mx-a Shunt Trip |
| Closing Release | Xf-e Closing Release |
| Electrical Characteristics | IEC 220/250V AC (50/60Hz), 200/220V DC |
| JIS/JEC Ratings | 200/250V AC (50/60Hz) |
| Circuit Breaker Category | Cat N° 685 658 |
| Breaker Accessory | Mp Breaker Accessory |
| Voltage (Accessory) | 240V AC - 60Hz - 20VA |
| Motor Mechanism | Mch-m Motor Mechanism |
| Motor Mechanism Accessory | Cat N° 685 763 |
| Tech Level | 01 |
| Additional Voltage | 200/240V AC (50/60Hz) |
| Spring Charge Switch | 10A at 240V AC |
| Weight | 69.300 kg |
| Additional Details | Tf2064 134 |
The Merlin Gerin M10 N1 Air Circuit Breaker 69 03 5 1 B 1000V AC 1000A is a robust and reliable electrical protection device designed to safeguard industrial and commercial electrical systems. With a nominal voltage rating (Ue) ranging from 380V to 690V and an ultimate voltage (Ui) of 1000V at 50/60Hz, this breaker offers versatile application capabilities across various power distribution setups.
Essential Features:
1.Voltage Ratings: It operates efficiently within a wide voltage range, accommodating both low voltage (380/440V) and high voltage (480/690V) systems.
2.Current Capacity: The M10 N1 breaker is capable of handling currents up to 1000A, ensuring effective protection against overload and short circuits.
3.Interrupting Capacity: With an Icu/Ics rating of 40ka, it can safely interrupt faults under heavy electrical loads, preventing potential damage to equipment and ensuring operational safety.
4.Durability: Designed to comply with IEC 947-2 standards, the breaker offers reliable performance and longevity in demanding industrial conditions.
5.Short-time Withstand Capacity: The Icw rating of 40ka for 0.5 seconds enhances its ability to withstand short-duration overload conditions without compromising on safety.
The Merlin Gerin M10 N1 Air Circuit Breaker combines advanced technology with robust construction, making it an ideal choice for critical power distribution applications where reliability and performance are vital. Whether used in manufacturing facilities, commercial buildings, or power generation plants, this breaker provides essential protection against electrical faults, ensuring continuous operation and minimizing downtime.
Utilizations:
1.Industrial Applications: In industrial contexts, the Merlin Gerin M10 N1 breaker is crucial for protecting machinery and equipment from electrical faults. Its high interrupting capacity (Icu/Ics 40ka) ensures swift isolation of faults, preventing damage and maintaining operational efficiency. Industries such as manufacturing, mining, and oil refineries rely on its robust design and dependable performance to safeguard their critical electrical systems.
2.Commercial Installations:Within commercial buildings and complexes, the M10 N1 breaker provides essential protection for electrical distribution networks. Its ability to handle high currents (up to 1000A) and diverse voltage ratings (380V to 690V) makes it suitable for applications ranging from office complexes to retail outlets. By ensuring reliable operation and quick fault clearance, it helps maintain uninterrupted power supply and protects valuable equipment from potential damage.
3.Power Generation Facilities: In power generation plants, where reliability is crucial, the Merlin Gerin M10 N1 breaker excels in safeguarding generators, transformers, and distribution panels. Its robust construction and high short time withstand capacity (Icw 40ka for 0.5 seconds) make it suitable for withstanding transient overloads and ensuring continuous power distribution. Whether used in conventional power plants or renewable energy installations, this breaker contributes to the overall reliability and safety of the electrical infrastructure.
The Merlin Gerin M10 N1 Air Circuit Breaker stands out as a versatile and dependable solution for critical electrical protection needs across various industries and applications. Its advanced features, including high current handling capacity, extensive voltage ratings, and compliance with international standards, make it a crucial component in modern electrical systems aimed at maximizing uptime and ensuring operational safety.
For optimal protection and reliability in industrial contexts, consider the Merlin Gerin NW10 H1 Air Circuit Breaker 1000A . Designed for superior performance, this product is an excellent complement to the Merlin Gerin M10 N1 Air Circuit Breaker 69 03 5 1 B 1000V AC 1000A, which offers robust circuit protection and exceptional durability. Both models are engineered to meet rigorous standards, ensuring that your electrical systems are safeguarded against overloads and short circuits with better efficiency.
