Measurement Technology
Measurement Technology Mtl 2314A Thc-input Temperature Trip Amplifier Type K 24Vdc
55663
10 in stock
Mtl Measurement Mtl 2314A Thc-input Temperature Trip Amplifier 24Vdc Type T
Mtl Measurement Technology Ltd
Mtl 2314A Thc-input Temperature Trip Amplifier
24V Dc
Type T
-5/+25 Mv
[Eexia] Iic
Baseefa No. Ex 822304
Bs 5501: Part 7 : 1977
En50 020
Umax: Out 8.9V
Imax: Out 53Ma
Maximum Ambient Temperature 60°C
Cext 4µF
Lext 12.5Mh
Cl I, Div. 1, Gp. A,B,C And D
Cl Ii, Div 1, Gp. E And G;
Cl Iii, Div.1
Vm= 250V R.M.S.
Voc 1.4V;
Isc 2.92Ma;
Ca 2.0µF;
La 1000Mh
Supply: 24V Dc Or 120V Ac Or 240V Ac, 5Va
Contact Rating: 250V Ac, 500Va, 5 Amp Max Resistive
Made In Usa
Weight: 520 Gm
