Merlin Gerin Masterpact M08 Ni Circuit Breaker Str 08 I 1000V

No reviews yet Write a Review
$2,999.99
Condition:
Used
SKU:
107479
Shipping:
Free Shipping
Quantity Type:
PCS
Short Description:

Merlin Gerin Masterpact M08 Ni Circuit Breaker Str 08 I 1000V
Merlin Gerin
Schneider Electric
Str 08 I
Masterpact
M08 Ni
Ui: 1000V~
Ue: 690V

Get a Quote
5 customers are viewing this product
Specification Details
Product Name Merlin Gerin Masterpact M08 Ni Circuit Breaker Str 08 I 1000V
Manufacturer Schneider Electric
Model Str 08 I
Series Masterpact M08 Ni
Ue 690V
Ui 1000V~
Frequency 50/60Hz
Icu 30kA 1S
Standards IEC 947-2
Series Number N-ata10184
Type M08 Ni 3Apps
Category Cat.B
Reference Number 1073019A
Manufacturing Code M 0103
Reference Number 0685878B
Series Number N-ata10181
Type M08 No 3Cpps
Rated Current (Ie) 10A/240V
Mechanism Type Mch-m
Motor Mechanism Category Number 685763
Rated Control Voltage (Uc) 200/240V AC (50-60Hz)
Control Voltage Ratings 240V 60Hz 180Va
Electrical Ratings E103955
Shunt Trip Type Mx-a
Closing Release Type Xf-e
Shunt Trip Category Number 685 658
Rated Control Voltage (Uc) 220/250V AC (50/60Hz)
Rated DC Control Voltage (Uc) 200/220V DC
Weight 64.500 Kg

The Merlin Gerin Masterpact M08 Ni Circuit Breaker, manufactured by Schneider Electric, is a robust solution designed for industrial electrical systems. With a nominal voltage rating of 690V and a maximum operational voltage of 1000V, it ensures reliable performance across a variety of applications. Operating seamlessly at both 50Hz and 60Hz frequencies, this circuit breaker is built to handle currents up to 30kA for 1 second, meeting IEC 947-2 standards for electrical safety.



Masterpact M08 Ni Circuit Breaker



Masterpact M08 Ni Circuit Breaker

Manufactured for durability and efficiency, the Masterpact M08 Ni features advanced components like the MCH-M motor mechanism, ensuring swift and precise operation during circuit interruptions. It includes a MX-A shunt trip for remote tripping capability and an XF-E closing release for controlled circuit reactivation. These features make it versatile for diverse industrial settings requiring dependable electrical protection. This circuit breaker model, identified by its reference numbers 1073019A and 0685878B, belongs to the N-ata10184 series and is classified as Type M08 Ni 3Apps under Cat.B. Its design integrates user-friendly functionalities, supporting ease of installation and maintenance in demanding environments. The inclusion of innovative technologies enhances operational safety and efficiency, ensuring uninterrupted power distribution across various industrial sectors. In terms of electrical specifications, the Masterpact M08 Ni supports 10A at 240V AC, catering to both standard and specialized electrical configurations. It complies with IEC standards for voltage ratings between 200V to 240V AC and 200V to 220V DC, making it adaptable to global electrical standards and requirements. The circuit breakers weight of 64.500 kg underscores its sturdy build, suitable for installations where reliability and longevity are vital.

Ideal for industrial facilities requiring robust electrical protection, the Merlin Gerin Masterpact M08 Ni Circuit Breaker offers a dependable solution with its comprehensive safety features and efficient operational capabilities. Whether in manufacturing plants, utility substations, or commercial complexes, its ability to handle high currents and voltages while ensuring safety makes it a preferred choice among professionals seeking reliable electrical distribution solutions.

For a higher capacity option within the Merlin Gerin Masterpact series, consider the Merlin Gerin Masterpact 1600Amp M16 H1 Circuit Breaker Str 38 S 1000V 50/60Hz . Designed to handle demanding electrical conditions with a maximum voltage of 1000V and frequencies of 50Hz and 60Hz, this model ensures robust protection and efficient power management. Featuring advanced safety mechanisms and durable construction, it offers reliability and performance ideal for industrial applications requiring high-current handling capabilities.
