Merlin Gerin Masterpact Nw32H2 Circuit Breaker 3200A Micrologic 5.0A
Merlin Gerin
Schneider Electric
Masterpact
Nw32H2
Ui 1000V
| Specification | Details |
|---|---|
| Product Name | Merlin Gerin/Schneider Masterpact Nw32H2 Micrologic 5.0A Circuit Breaker 3200Amp |
| Manufacturer | Merlin Gerin, Schneider Electric |
| Series | Masterpact |
| Model | Nw32H2 |
| Ui | 1000V |
| Uimp | 12Kv |
| Ue | 220/440V~ Icu: 100Ka |
| Ue | 525/690V~ Icu: 85Ka |
| Ics | 100% Icu |
| Icw | 85Ka/1S |
| Category | B |
| Standards | Iec 60947-2, Iec 60947-3 |
| Frequency | 50/60Hz |
| AC23A Rating | 690V 3200A |
| Interrupting Rating (Ka) |
240/480V~ 100 600V~ 85 |
| Nema | Ab1 |
| Type | Retrofit Breaker |
| Rcs N° | Pp0166 |
| Micrologic | 5.0A |
| In | 3200A |
| Type |
Nw08-40 H1-h2 Nw08-40 Ha-hf |
| Voltage | 220/440Vac |
| Motor Mechanism | Mch/Xm |
| Motor Mechanism Voltage | 200-240 Vac 50-60-400Hz |
| Product Numbers |
47894 009162478948 A09162 038H 04441862Ea 033662 |
| Control Units | Mx-xf/Sht-shc |
| Control Unit Voltage | 200-250 Vac-dc |
| Certification Numbers |
E161835 E63335 51066271 A08414 38H 000005106662101302976081 |
| Country of Manufacture | France |
| Weight | 51 Kg |
The Merlin Gerin/Schneider Masterpact NW32H2 Micrologic 5.0A Circuit Breaker stands as a top of industrial electrical protection, designed by Schneider Electric with precision and reliability in mind. This robust breaker is rated at 3200A, making it ideal for durable applications where large currents must be safely managed. Built to the highest standards of manufacturing excellence, it complies with IEC 60947-2 and IEC 60947-3 specifications, ensuring compatibility and adherence to international electrical standards.
At its core, the Masterpact NW32H2 features advanced Micrologic 5.0A technology, enhancing its ability to accurately monitor electrical parameters and provide precise protection against faults. This microprocessor-based system enables real-time data collection and analysis, facilitating proactive maintenance and reducing downtime. With an impressive interrupting capacity (Icu) of 100ka at 220/440V and 85ka at 525/690V, it guarantees reliable operation even under extreme fault conditions, ensuring the continuity of operations in critical environments. Designed for versatility, the NW32H2 supports a wide range of operational voltages, from 220V to 690V, accommodating various industrial applications with ease. Its dual voltage ratings of 220/440V and 525/690V underscore its adaptability across different power systems and geographical locations. The breakers Ac23A rating at 690V and 3200A further highlights its suitability for motor load switching, demonstrating its capability to handle high inrush currents without compromising performance. As a retrofit breaker, the NW32H2 integrates seamlessly into existing electrical systems, offering a straightforward upgrade path for enhancing circuit protection without requiring extensive modifications. This feature not only simplifies installation but also minimizes downtime during upgrades or replacements, making it a cost-effective choice for facility seeking to modernize their infrastructure while maintaining operational continuity.
The Masterpact NW32H2 is housed in a robust enclosure capable of withstanding harsh industrial conditions. Its design incorporates high-quality materials and particular craftsmanship, ensuring longevity and reliability under demanding operating conditions. With a weight of 51 kg, it strikes a balance between roughness and manageability, facilitating both installation and maintenance tasks. Manufactured in France, each NW32H2 breaker undergoes rigorous quality control processes to meet Schneider Electric harsh performance and safety standards.
The Merlin Gerin/Schneider Masterpact NW32H2 Micrologic 5.0A Circuit Breaker represents a top of innovation and reliability in the area of industrial circuit protection. Whether used in power distribution networks, manufacturing facilities, or crucial infrastructure applications, it delivers unparalleled performance, safety, and longevity.
For those seeking high-performance circuit breakers, this product, the Merlin Gerin NT12 H1 Micrologic 5.0A Masterpact Circuit Breaker 1250A 50/60Hz , offers exceptional reliability and advanced protection features. Explore this product to discover its robust design and capabilities, ensuring optimal safety and efficiency for your electrical systems.
