Merlin Gerin Nw12 H1 Micrologic 5.0A Air Circuit Breaker 1200Amp 50/60Hz
Merlin Gerin
Masterpact
Nw12 H1
Ui: 1000V
Uimp 12Kv
Ics=100%Icu
Icw 65Ka/1S
| Specification | Details |
|---|---|
| Product Name | Merlin Gerin Nw12 H1 Micrologic 5.0A Air Circuit Breaker 1200Amp 50/60Hz |
| Brand | Merlin Gerin |
| Series | Masterpact |
| Model | Nw12 H1 |
| Ui | 1000V |
| Uimp | 12kV |
| Ics | 100%Icu |
| Icw | 65Ka/1S |
| Category | B |
| Standard | IEC 60947-2 50/60Hz |
| Ue (V) | 690 |
| Ie (A) | 1250 |
| Ac23A | 690V / 1250A |
| Ac3 | 690V / 1250A |
| Micrologic Type | Micrologic 5.0A |
| In (Rated Current) | 1250A |
| E Number | E103955 |
| Mch | 100-130Vac |
| Xf/Mx/Mn | 100-130Vac/Vdc |
| Mch (200-240Vac) | 200-240Vac |
| Xf | 200-250Vdc/Vac |
| Mx | 24-30Vdc/Vac |
| Catalog Number | 04441862Da |
| Mx-xf/Sht-shc | Mn/Uvr |
| Mn/Uvr | 100-130V Ac-dc |
| Mch/Xm (Motor Mechanism) | 100-130Vac 50-60-400Hz |
| Serial Number | 004111478932 |
| E Number | E161835 |
| E Number | E63535 |
| Product Code | Nw12H13Pew6.0A |
| Product Code | Nw12H13Pew6.0A837420206 |
| Barcode | 000005106662101101089128 |
| Current Rating | 1200A |
| Weight | 79.500 Kg |
The Merlin Gerin NW12 H1 Micrologic 5.0A Air Circuit Breaker is a top-tier solution for managing electrical systems efficiently and safely. Part of the renowned Masterpact series by Merlin Gerin, this circuit breaker is manufactured to provide reliable performance and robust protection for various applications. Its advanced features and adherence to international standards make it an ideal choice for both industrial and commercial settings.
Designed for high-voltage operations, the NW12 H1 can handle up to 1000V with a current rating of 1200A. It features a Uimp (impulse withstand voltage) of 12kV, ensuring it can withstand high transient voltages, a crucial aspect for maintaining system integrity under varying conditions. The circuit breakers performance is further underscored by its Ics, which is 100% of Icu, and Icw, which is 65kA for 1 second. This makes the NW12 H1 highly reliable in fault conditions, capable of handling high fault currents without compromising performance. The Micrologic 5.0A trip unit integrated into this breaker offers advanced protection features. It allows for precise monitoring and control, ensuring optimal performance and safety. The NW12 H1 is compatible with various power inputs, including 100-130V AC/DC and 200-240V AC, enhancing its flexibility across different electrical systems. Additionally, its motor mechanism (MCH) and control options (XF/MX/MN) cater to various operational requirements, making it adaptable for different applications.
Compliance with IEC 60947-2 and IEC 60947-3 standards underscores the breakers quality and safety. It is designed for use in AC23A and AC3 applications, with a rated current of 1250A at 690V, making it suitable for demanding industrial conditions. The breakers robust construction ensures long-term reliability, reducing the risk of downtime and enhancing overall system efficiency. Weighing 79.5 kg, the NW12 H1 is built to withstand the rigors of industrial use. Its solid construction not only ensures durability but also contributes to its stability during operation. The breakers compact design and ease of installation further add to its appeal, making it a practical choice for various electrical systems. The Merlin Gerin NW12 H1 Micrologic 5.0A Air Circuit Breaker is equipped with advanced features that prioritize safety and efficiency. Its ability to handle high voltages and currents, coupled with its precise trip unit, makes it a reliable component in any electrical infrastructure. Whether for protecting critical equipment or ensuring uninterrupted power supply, this circuit breaker is designed to meet the highest standards of performance and safety.
The Merlin Gerin NW12 H1 Micrologic 5.0A Air Circuit Breaker is a high-performance, reliable, and safe solution for managing electrical systems. Its adherence to international standards, robust construction, and advanced features makes it an ideal choice for a wide range of applications.
For a reliable solution similar to the Merlin Gerin Nw12 H1 Micrologic 5.0A Air Circuit Breaker 1200Amp 50/60Hz, consider exploring the the Merlin Gerin Nw12 H1 Micrologic 5.0A Circuit Breaker 1250A 1000V . This breaker offers advanced protection features, handling up to 1000V with a current rating of 1250A, and is designed to meet international standards, ensuring optimal performance and safety in various industrial applications.
