Merlin Gerin Nw12 H1 Micrologic 6.0A Circuit Breaker Trip Unit 1250A 1000V
Merlin Gerin
Schneider Electric
Micrologic 6.0A
Masterpact
| Specification | Details |
|---|---|
| Product Name | Merlin Gerin NW12 H1 Micrologic 6.0A Circuit Breaker Trip Unit 1250A 1000V |
| Brand | Merlin Gerin |
| Manufacturer | Schneider Electric |
| Trip Unit Model | Micrologic 6.0A |
| Series | Masterpact |
| Model | NW12 H1 |
| Ui (Rated Insulation Voltage) | 1000V |
| Uimp (Impulse Withstand Voltage) | 12kV |
| Ue (Operational Voltage) | 220/440~, 480/690~ |
| Icu (Ultimate Breaking Capacity) | 65kA |
| Ics (Service Breaking Capacity) | 100% Icu |
| Icw (Rated Short-Time Withstand Current) | 65kA/1s |
| Category | Cat. B |
| Standards Compliance | IEC 60947-2, 50/60Hz |
| Utilization Category | AC23A/AC3 |
| Rated Operational Voltage | 690V |
| Rated Current | 1200A |
| Additional Standards | IEC 60947-3, 50/60Hz |
| In (Rated Current) | 1250A |
| Product Code | NW12H13PEW6 0A |
| Part Numbers | 83742, GH800017AA, K08455, 41605, 008245478943, 47894/GHJ10156AA, H08245, 04441862EA, 033662 |
| Control Circuit Voltage | MCH 200/240VAC |
| Additional Part Numbers | MX-XF/SHT-SHC 24VAC-24/30VDC, 08382, 33659, MX-XF/SHT-SHC 200-250V AC-DC, W08061, 33662 |
| Type | Circuit Breaker Trip Unit |
| Compliance Marks | E161835, E63335 |
| Country of Manufacture | France |
| Weight | 79.700 kg |
When it comes to ensuring the safety and efficiency of your industrial electrical systems, NW12 H1 Micrologic 6.0A Circuit Breaker Trip Unit stands out as a premier choice. Manufactured by Schneider Electric under the renowned Merlin Gerin brand, this circuit breaker offers strong protection and exceptional performance for demanding industrial applications.
Main Features
The Merlin Gerin NW12 H1 Micrologic 6.0A Circuit Breaker is designed to handle high-voltage and high-current scenarios with ease. Here are its main features:
1.Voltage Ratings: This circuit breaker supports an operational voltage (Ui) of up to 1000V, making it suitable for high-power applications. It can handle different voltage levels, including 220/440V and 480/690V, ensuring versatility across various electrical systems.
2.Impulse Withstand Voltage: With an impulse withstand voltage (Uimp) of 12kV, the NW12 H1 is well-equipped to protect against electrical surges and spikes, safeguarding your equipment and infrastructure.
3.Breaking Capacity: The circuit breaker boasts a high interrupting capacity (Icu) of 65kA, ensuring it can effectively handle short-circuit conditions. Its service breaking capacity (Ics) is 100% of Icu, providing reliable performance even under fault conditions.
4.Continuous Current Rating: With a continuous current rating (In) of 1250A, this circuit breaker is suitable for heavy-duty applications, delivering consistent performance over prolonged periods.
5.Short-Time Withstand Current: The NW12 H1 has a short-time withstand current (Icw) of 65kA for 1 second, allowing it to manage high fault currents without damage.
6.Advanced Micrologic 6.0A Trip Unit: The Micrologic 6.0A trip unit integrated into the NW12 H1 circuit breaker provides advanced protection and monitoring features. This trip unit is designed to offer precise and reliable protection against overloads, short circuits, and ground faults. It ensures optimal performance and safety by continuously monitoring the electrical parameters and responding quickly to any anomalies.
7.Versatility and Compatibility: One of the standout features of the Merlin Gerin NW12 H1 is its versatility. It can be used in a wide range of industrial applications, including manufacturing plants, power distribution systems, and commercial facilities. Its ability to handle different voltage levels and high current ratings makes it a reliable choice for various electrical setups.
The Merlin Gerin NW12 H1 Micrologic 6.0A Circuit Breaker Trip Unit is a top-tier solution for industrial electrical protection. Its advanced features, high performance, and robust construction make it an ideal choice for a wide range of applications. Whether you need reliable protection for power distribution systems, manufacturing plants, or commercial facilities, this circuit breaker delivers exceptional performance and safety.
For robust protection and reliable performance in high-voltage applications, consider the Merlin Gerin Masterpact Nw12 N1 Circuit Breaker Micrologic 6.0A 50/60Hz 1200A . Operating at 50/60Hz with a 1200A rating, it offers advanced features and exceptional safety, similar to the Merlin Gerin Nw12 H1 Micrologic 6.0A Circuit Breaker Trip Unit 1250A 1000V.
