Merlin Gerin Nw12H1 Micrologic 5.0 A Circuit Breaker 1000V 1200A
Merlin Gerin
Masterpact
Micrologic 5.0A
Nw12H1
Ui 1000V
Uimp 12Kv
Ics = 100% Icu
| Specification | Details |
|---|---|
| Product Name | Merlin Gerin Nw12H1 Micrologic 5.0 A Circuit Breaker 1000V 1200A |
| Brand | Merlin Gerin |
| Series | Masterpact |
| Trip Unit | Micrologic 5.0A |
| Model | Nw12H1 |
| Ui | 1000V |
| Uimp | 12kV |
| Ics | 100% Icu |
| Icw | 65kA/1s Cat.B |
| Standard Compliance | IEC 60947-2 50/60 Hz |
| Ue | 690V |
| Ie | 1200A |
| Utilization Category | Ac23A, Ac3 |
| Ue | 690V |
| Ie | 1200A |
| Standard Compliance (Switching Devices) | IEC 60947-3 50/60Hz |
| In | 1250A |
| Mechanism | Mch/Xm Motor Mechanism |
| Control Voltage | 100-130Vac 50-60-400Hz |
| Product Number | 47893 |
| EAN/UPC | 005424478930 |
| Current Rating | 1200A |
| Weight | 78.550 Kg |
The NW12 H1 Micrologic 5.0A Circuit Breaker. Manufactured to meet the highest standards of electrical protection, this breaker is ideal for industrial applications demanding precision and robustness. With a rated voltage of up to 1000V and a current rating of 1200A, it ensures efficient operation across various condtions, from durable manufacturing plants to critical infrastructure installations. The Micrologic 5.0A technology enhances operational safety by offering precise measurements and advanced trip unit functions, ensuring rapid response to potential faults while minimizing downtime. Whether used in AC23A or AC3 applications at 690V, its Ics = 100% Icu capability and Icw 65Ka/1S Cat.B performance provide reliable protection under various operational conditions, adhering to IEC 60947-2 standards for 50/60Hz frequencies.
Built for durability, the Merlin Gerin NW12 H1 Micrologic 5.0A Circuit Breaker features a robust construction that withstands rigorous industrial condtions. Its Mch/Xm motor mechanism operates seamlessly within voltage ranges of 100-130Vac and frequencies ranging from 50-60-400Hz, ensuring consistent performance across fluctuating power supplies. With a weight of 78.550 kg, this breaker is designed for ease of installation and maintenance, supported by its straightforward configuration and dependable operation. It complies with IEC 60947-3 standards, offering peace of mind with its comprehensive protective features and reliability in safeguarding electrical circuits against overload and short-circuits conditions.
Ideal for applications requiring high levels of electrical reliability and performance, the Merlin Gerin NW12 H1 Micrologic 5.0A Circuit Breaker stands out for its efficiency and versatility. Whether deployed in manufacturing facilities, utilities, or commercial buildings, it delivers optimal performance with minimal maintenance requirements. The breakers Ui 1000V and Uimp 12kV ratings underscore its capability to handle transient overvoltages, ensuring continuous operation even in challenging electrical environments. Its precision-manufactured components and advanced trip unit technology enable quick response times to fault, mitigating potential risks and maximizing uptime for critical operations.
Experience enhanced operational efficiency and safety with the Merlin Gerin NW12 H1 Micrologic 5.0A Circuit Breaker. Designed to exceed expectations in industrial applications, it combines robust construction with intelligent features to provide comprehensive electrical protection. The breakers adherence to IEC standards reflects its reliability and performance in safeguarding equipment and personnel from electrical hazards. Whether used in demanding manufacturing processes or essential infrastructure, it offers a reliable solution customized to meet the demands of modern industrial operations. Ensure continuity and reliability in your electrical systems with the Merlin Gerin NW12 H1 Micrologic 5.0A Circuit Breaker, setting new benchmarks in electrical protection and operational efficiency.
Explore our range of advanced circuit protection solutions with the the Merlin Gerin NW12 H1 Micrologic 6.0A Circuit Breaker Trip Unit 1250A 1000V . Designed for high-performance industrial conditions, this breaker combines robust construction with enhanced trip unit capabilities, ensuring precise protection against overloads and short circuits. With its advanced Micrologic 6.0A technology, it offers better-quality monitoring and control, optimizing operational efficiency while maintaining safety standards. Ideal for applications requiring reliable electrical protection and seamless integration, this breaker sets a benchmark in reliability and performance across various industrial sectors.
