Parker Lucifer 49590502 Hz96C2 Solenoid Valve Ip67 24V 360 Ma
Parker Lucifer Sa
Manufacturer: Semco Maritime
P/N: 49590502 Hz96C2
Ex D Mb Iic T4
Tamb.: -40 A +65°C
Ip67
Td A21 T +130°C
Iec Ex Lci 06.0004 X
| Product | Details |
|---|---|
| Manufacturer | Parker Lucifer SA |
| Part Number | 49590502 Hz96C2 |
| Ex Rating | Ex D Mb Iic T4 |
| Temperature Range | Tamb.: -40 to +65°C |
| Ingress Protection | IP67 |
| Max Temp Rating | Td A21 T +130°C |
| IEC Ex Certification | IEC Ex Lci 06.0004 X |
| Supply Voltage | Un: 24V= |
| Current Rating | In: 360 mA |
| ATEX Certification | Lcie 03 Atex 6451 X |
| Torque For Cover | 1.5 to 2 Nm |
| Reference Code | 496489 |
| Another Reference | 496548 |
| Additional Code | 33637 |
| Another Code | 7133Tvn2Gv00 |
| Another Code | 4907E |
| Manufacturing Part | 7131Tvn2Jv00/495905 |
| Valve Type | Valve, Solenoid, Ex |
| Model | Fire Fighting System |
| Manufacturer | Semco Maritime |
| Account | 7426000 742-90132 1Oh |
| Country of Origin | Made In Switzerland |
| Weight | 820 Gm |
The Parker 49590502 Hz96C2 Solenoid Valve is a heavy-duty and very reliable component from Parker Lucifer SA, which can be used in demanding environments, most especially fire fighting system apparatus. The valve is rated as Ex D Mb Iic T4; hence the particular valve is subject to very tight safety standards for explosive atmospheres. The operating temperature range is between -40°C up to +65°C and another maximum rating up to +130°C.
Its ingress protection rating is IP67, which means it protects the valve from dust and water penetration, thus allowing it to be more suitable for harsh conditions. The Parker solenoid valve has an input voltage of 24V and a current rating of 360 mA, ensuring operation in various applications without loss of efficiency. The torque for the cover is specified between 1.5 to 2 Nm, which ensures easy assembly.
This valve has an appropriate installation and maintenance procedure with several reference numbers and part numbers, such as 7133Tvn2Gv00 and 495905. It is characterized by a weight of 820 grams and manufactured in Switzerland, thereby indicating very high standards of engineering skills. The Parker 49590502 Hz96C2 is an important element to make sure the fire fighting systems, as well as other important systems, function without fail.
1. Manufacturer : Parker Lucifer SA is a company with a good reputation for manufacturing quality products of different industrial standards.
2. Model Number/Code Number : It can be easily referred to as Part 49590502 Hz96C2.
3. Explosion-Proof Rating : Code Ex D Mb Iic T4 rating ensures that the rated product is safe for use in explosive environments.
4. Temperature Range : Operating range of -40°C +65°C with maximum rated temperature at +130°C.
5. Ingress Protection : Rated IP67, thereby dust tight and waterproof with an open environment in hostile environments.
6. Input Voltage : 24V DC with input voltage, compatible with standard systems.
7. Current Rating : It is rated at 360 mA and can be used in a wide range of functions, so you do not have to worry about running out of sufficient current for smooth operation.
8. ATEX Certification : It complies with Lcie 03 Atex 6451 X to meet the safety criteria of the European Union, where equipment is installed in hazardous situations.
9. Torque Specifications : The torque value for the cover is between 1.5 to 2 Nm.
10. Valve Type : Designed as a solenoid valve for controlling fluid flow in critical applications, including fire fighting systems.
11. Manufacturer's Part : Includes manufacturing part number 7131Tvn2Jv00/495905 for additional identification.
12. Weight : Weighs 820 grams, making it manageable for installation and maintenance.
13. Versatile Applications : Suitable for a variety of applications, particularly in industrial and fire safety systems, where reliable performance is essential.
1. Fire Fighting Systems: Used in fire suppression systems to control water or foam flow, ensuring effective firefighting capabilities.
2. Industrial Automation: Applied in automated systems for controlling the flow of liquids and gases in manufacturing processes.
3. Oil and Gas Industry: Utilized in oil and gas operations for controlling the flow of hydrocarbons, enhancing safety and efficiency.
4. Water Treatment Plants: Applied in water treatment and wastewater treatment plants for controlling chemicals flow and treated water.
5. Chemical Plants: Applied in chemical plant use for regulating flow of several liquids and accurate dosing of all chemicals.
6. HVAC Applications: Used in heating, ventilation, and air-conditioning systems for the fluid flow control and energy management
7. Hydraulic Applications: Used in hydraulic circuits for managing the hydraulic fluid flow so that machinery may work most effectively.
8. Marine Applications: Used in marine environments for controlling the flow of water or fuel in ships and offshore platforms.
9. Pneumatic systems: Applied in pneumatic applications for the control of air flow and pressure in systems.
10. The food and beverage industry: Applied for food processing and beverage production for controlling liquid flows in a hygienic way.
Ensure reliable flow control in your systems with the Parker 49590502 Hz96C2 Solenoid Valve. Explore related products available now at Aeliya Marine for top-notch performance!
