Schneider Electric Nw16 N1 Masterpact Circuit Breaker 1600 Amp
Schneider Electric
Merlin Gerin
Santon
Ecofit
Type Of Protection: Micrologic 5.0E
| Specification | Details |
|---|---|
| Product Name | Schneider Electric Nw16 N1 Masterpact Circuit Breaker 1600 Amp |
| Brand | Schneider Electric, Merlin Gerin, Santon, Ecofit |
| Type Of Protection | Micrologic 5.0E |
| Model | Masterpact Nw16 N1 |
| Ui | 1000V |
| Uimp | 12Kv |
| Ue (V) | 220/440~, 480/690~ |
| Icu (Ka) | 42 |
| Ics | 100% Icu |
| Icw | 42Ka/1S Cat.B |
| Standards | Iec 60947-2 50/60 Hz |
| Set Point | 10Q1 |
| Io | 1 |
| Ir | 1 |
| Im | 5 |
| Tm | 0.2 (On) |
| I | Off |
| In | 1600A |
| Product Code | 3N14331 |
| N1 | Mch 200-240 Vac, Mx 200-250 Vac/Vdc, Xf 200-250 Vac/Vdc, Mn 200-250 Vac/Vdc, R 200-250 Vac/Vdc |
| Order Number | 51066621A |
| N Moyen/N Medium | 3 |
| Reference Code | 142315106662101003238786 |
| A Code | 14231 |
| Mn/Mx2 Mx1 | Xf, Mn/Uvr, 200-250 Vac-dc, 3N14323 33671, Mx-xf/Sht-shc, 200-250 Vac-dc, 3N14344 33662 |
| Order Number | 175711 |
| Reference | 0685878B |
| Type | M16 |
| Number | 3Cpps |
| Mechanism | Mch/Xm Motor Mechanism 200-240 Vac 50-60-400Hz |
| Product Code | 47894, 014344478944, A14344 038H, A91, 51066271 |
| N˚ | 20202512473 |
| 380 | Gcr_Pp_Nw_Cb |
| Feature | Plug & Play |
| Reference Number | 7077, S80003218 |
| Type Of Breaker | Masterpact Nw 16 N3 |
| Type Of Installation | Withdrawable |
| Gear Motor | 200/240 Vac |
| Coil | Undervoltage/ Closing/ Opening Coil: 200/250 Vac |
| Contacts | Indication Contacts: 4Xof+Sde |
| Country | Made In France |
| Weight | 76 Kg |
The Schneider Electric NW16 N1 Masterpact Circuit Breaker 1600 Amp is a high-performance electrical protection device designed to ensure the safety and reliability of power distribution systems. Manufactured by Schneider Electric, a leader in energy management and automation, this circuit breaker incorporates advanced features to provide robust protection against electrical faults. With a rated current of 1600A, the NW16 N1 is suitable for a wide range of industrial applications, offering better reliability and efficiency.
Advanced Protection with Micrologic 5.0E Technology
One of the standout features of the NW16 N1 Masterpact Circuit Breaker is its integration of Micrologic 5.0E protection technology. This advanced electronic protection unit enhances the breaker's capability to detect and respond to a variety of electrical anomalies. Micrologic 5.0E provides precise protection settings, ensuring optimal performance and safety. The breaker operates within a voltage range of 220/440V and 480/690V, making it versatile for various power systems. With a rated ultimate short-circuit breaking capacity (Icu) of 42kA and a rated service short-circuit breaking capacity (Ics) equal to 100% of Icu, it guarantees maximum protection under extreme fault conditions. The NW16 N1 Masterpact Circuit Breaker is designed to meet the requirements of IEC 60947-2 standards, ensuring high-quality performance and safety. Its impulse withstands voltage (Uimp) of 12kV and rated insulation voltage (Ui) of 1000V further enhances its reliability. The breaker boasts a short time withstand current (Icw) of 42kA for 1 second, classified under category B, making it ideal for demanding industrial conditions. The robust construction and adherence to international standards make this circuit breaker a reliable choice for critical power protection applications.
The NW16 N1 is designed for easy integration and flexibility in various installations. It features a withdrawable installation type, allowing for convenient maintenance and replacement. The gear motor operates on 200/240 Vac, ensuring smooth and reliable operation. Additionally, the breaker includes an undervoltage/closing/opening coil rated at 200/250 Vac, providing enhanced control and safety during power interruptions. Indication contacts (4Xof+Sde) are included to facilitate monitoring and diagnostics, ensuring efficient system management. The breaker is also equipped with a motor mechanism Mch/Xm that operates on 200-240 Vac, suitable for 50-60-400Hz applications, further enhancing its versatility and control capabilities.
Comprehensive Features
The Schneider Electric NW16 N1 Masterpact Circuit Breaker comes with a range of accessories and features designed to enhance its functionality and ease of use. The breaker is equipped with indication contacts and auxiliary control circuits that operate on 200-250 Vac/Vdc, providing comprehensive control options. The model number 3N14331 ensures precise identification and compatibility with related system components. With a weight of 76 kg, the breaker is robust yet manageable for installation and maintenance. The product is made in France, reflecting Schneider Electric assurance to quality and innovation in power management solutions. The NW16 N1 Masterpact Circuit Breaker is designed for plug-and-play installation, simplifying the setup process and reducing downtime. The breaker includes a gear motor and control circuits that operate within a 200-250 Vac/Vdc range, ensuring compatibility with various power systems. Order number 175711 and reference 0685878B ensure easy identification and procurement of the breaker and its components. The breaker is type M16 with the designation 3Cpps, and it includes a comprehensive motor mechanism for efficient operation. The plug-and-play design, along with its robust construction, makes this circuit breaker a reliable and convenient choice for industrial power protection applications.
The Schneider Electric NW16 N1 Masterpact Circuit Breaker 1600 Amp is a top-tier solution for industrial power protection. Its advanced Micrologic 5.0E technology, robust design, and compliance with international standards make it a reliable choice for ensuring the safety and efficiency of power distribution systems. With versatile installation options, comprehensive accessories, and plug-and-play functionality, the NW16 N1 is designed to meet the demanding needs of modern industrial applications. Choose the Schneider Electric NW16 N1 Masterpact Circuit Breaker for better performance and reliability in your power management solutions.
For a higher capacity and similar advanced features, consider the Schneider Electric NW25 H1 Masterpact Circuit Breaker 2500 Amp . This robust circuit breaker offers enhanced protection and reliability for more demanding industrial applications, ensuring optimal performance with its modern Micrologic protection technology and compliance with international standards.
