Terasaki Electric Ar440Sb-r Air Circuit Breaker 50/60Hz 1000V
Terasaki Electric (Europe) Ltd.
Tempower 2
Accessories
Ar440Sb-r
| Specificstion | Details |
|---|---|
| Product Name | Terasaki Electric Ar440Sb-r Air Circuit Breaker 50/60Hz 1000V |
| Manufacturer | Terasaki Electric (Europe) Ltd. |
| Model | Tempower 2 |
| Accessories | Ar440Sb-r |
| Standards | En 60947-2, Iec 60947-2, As 3947.2 |
| Poles | 3 |
| Frequency | 50/60Hz |
| Ui (Rated Insulation Voltage) | 1000V |
| Uimp (Impulse Withstand Voltage) | 12Kv |
| In Max. (Maximum Rated Current) | 4000A |
| Icw (Rated Short-time Withstand Current) | 1 Sec: 100Ka, 3 Sec: 75Ka |
| Category | Cat.B |
| Product Code | 1H1446Sab |
| Uvt Control Device | Type: Aur-1Cd |
| Over-current Release | Type: Agr-21Bs-ps |
| CT Rated Current (Ict) | 4000A |
| Rated Current (In) | 3208A |
| Component Code | 1A5480Sab |
| Z-5405-2 | 3518Can |
| Version | 002F |
| Uvt Coil | Aur-1C |
| Uvt Coil Component Code | 1A5446Saa |
| Uvt Coil Voltage | 110 Vac Uvt 0.5 Sec Time Delay |
| Magnet Hold Trigger | Atr-1 |
| Current Sensor | Acr-340R |
| Current Sensor Voltage | 125Mv (50Hz), 150Mv (60Hz) |
| Current Sensor Component Code | 1A4392Sga |
| Motor Charge Unit | Amr-1B 1C |
| Motor Charge Unit Voltage | 1B: Ac 100V-120V 50/60 Hz, Dc 100V-110V, 1C: Ac 100V-240V 50/60 Hz |
| Motor Charge Unit Component Code | 1H5163Cca-k |
| Latch Release Coil | 110 Vac |
| Latch Release Coil Component Code | M010 10Ab Std Aux Sw-marine |
| IP Rating (Door Flange) | Ip31 |
| Generator Full Load Current | Flc In= 3208A |
| Chassis Protection | H05260, Ip3X |
| Country of Manufacture | Japan |
| Weight | 130 Kg |
The Terasaki Electric AR440SB-R Air Circuit Breaker is a strong solution for high-voltage applications, designed to meet rigorous standards and ensure reliable performance. Operating at frequencies of 50/60Hz and a maximum voltage of 1000V, it conforms to EN 60947-2 and IEC 60947-2 regulations, as well as AS 3947.2 standards. This circuit breaker features three poles, making it suitable for industrial automation where power distribution and protection are critical. With a short-circuit breaking capacity (Icw) of 100kA for 1 second and 75kA for 3 seconds, it guarantees swift and effective response to electrical faults, minimizing downtime and enhancing safety.
Key components like the UVT control device (type AUR-1CD) and over-current release (type AGR-21BS-PS) ensure precise operation and protection against overloads. The rated current (In) stands at 3208A, with a maximum rated current (In max) of 4000A, accommodating heavy electrical loads seamlessly. Additional accessories such as the motor charge unit (AMR-1B 1C) and current sensor (ACR-340R) provide supplementary functionalities, enhancing the circuit breakers versatility in different applications. The 110VAC latch release coil (1H5163CCA-K) and IP31 door extension underline its suitability for various environmental conditions, including marine applications. Manufactured in Japan with particular attention to detail, the AR440SB-R boasts a robust construction weighing 130 kg, ensuring durability and reliability in demanding operational environments. Its IP3X chassis protection and generator FLC capabilities further enhance its suitability for rigorous industrial use.
The Terasaki Electric AR440SB-R Air Circuit Breaker stands out as a high-performance solution that combines advanced technology with compliance to international standards. Whether used in manufacturing facilities, industrial projects, it delivers supreme reliability and safety, backed by Terasaki Electric for quality and innovation in electrical protection solutions.
If you are interested in the Terasaki Electric Ar440Sb-r Air Circuit Breaker 50/60Hz 1000V, you may also want to explore the Terasaki Electric Ar440Sb-r Air Circuit Breaker 1000V . This product offers robust performance and reliability, ensuring optimal protection for your electrical systems.
