Terasaki Xs1600Ne 3 Pole Circuit Breaker Ac690V 50~60Hz 1600Amp
Terasaki Electric Co., Ltd.
Tembreak
Circuit Breaker
Xs1600Ne
Ui: Ac690V 50~60Hz
800, 900, 1000
1200,1400,1600A
1600A
| Specification | Details |
|---|---|
| Product Name | Terasaki Xs1600Ne 3 Pole Circuit Breaker Ac690V 50~60Hz 1600Amp |
| Manufacturer | Terasaki Electric Co., Ltd. |
| Series | Tembreak |
| Type | Circuit Breaker |
| Model | Xs1600Ne |
| Rated Voltage (Ui) | Ac690V 50~60Hz |
| Rated Current (In) | 800, 900, 1000, 1200, 1400, 1600A |
| Max Rated Current | 1600A |
| Number of Poles | 3 Pole |
| Part Number | 2H0757Saa/K |
| Short-time Withstand Current | 25Ka 0.3 Sec |
| Motor Operator | 2H0763Sba/K |
| Motor Operator Type | Xmc 9 |
| Motor Operator Voltage | Ac 100~115V |
| Motor Operator Current | 1.0A |
| Auxiliary Switch | 2H1035Saa |
| Auxiliary Switch Voltage (AC) | Ac480V 3A, Ac250V 5A |
| Auxiliary Switch Voltage (DC) | Dc250V 0.3A, Dc125V 0.6A |
| Auxiliary Switch Part Number | 2H1023Sac |
| Country of Origin | Made In Japan |
| Weight | 39.650 Kg |
The XS1600NE 3 Pole Circuit Breaker, manufactured by Terasaki Electric Co., Ltd., embodies advanced technology and robust design, customized for industrial electrical protection. This breaker is part of the renowned Tembreak series, designed to safeguard electrical systems operating at 690V Ac, with a frequency range of 50-60Hz. With current ratings spanning from 800A to 1600A, the XS1600NE offers versatile solutions for various industrial applications, ensuring reliable performance and protection.
Advanced Features
At its core, the XS1600NE boasts a high interruption capacity, designed to handle short time withstand currents of 25ka for 0.3 seconds. This critical feature ensures that the breaker can manage high fault currents without compromising the integrity of the electrical system. The breaker is equipped with a motor operator, type XMC 9, which operates at 100-115V Ac with a current rating of 1.0A, enabling remote operation and automation capabilities. This integration allows for enhanced control and monitoring, crucial for modern industrial setups.
The Terasaki XS1600NE includes a range of auxiliary switches to extend its functionality and control. The auxiliary switch, model 2H1035Saa, supports multiple voltage and current ratings, including 480V AC at 3A, 250V DC at 0.3A, 250V AC at 5A, and 125V DC at 0.6A. These auxiliary components enhance the breaker's versatility, allowing it to interface seamlessly with other control and protection devices within the electrical system. This feature ensures comprehensive system monitoring and protection, reducing the risk of electrical faults and downtime.
Crafted with precision in Japan, the Terasaki XS1600NE 3 Pole Circuit Breaker is built to withstand the rigors of demanding industrial conditions. Weighing 39.650 kg, its robust construction ensures durability and longevity, making it a reliable choice for heavy-duty applications. The breaker high-quality materials and long-lasting manufacturing processes underscore Terasaki assurance to delivering superior electrical protection solutions. This focus on quality and reliability ensures that the XS1600NE can handle the operational stresses of industrial situations, providing consistent and dependable performance. The XS1600NE is designed for seamless integration into existing electrical systems, facilitating straightforward upgrades and replacements without significant modifications. This adaptability minimizes downtime during installation and maintenance, offering a cost-effective solution for enhancing circuit protection. Additionally, the breaker complies with international electrical standards, ensuring compatibility and safety across various industrial applications.
The Terasaki XS1600NE 3 Pole Circuit Breaker AC690V 50-60Hz 1600Amp represents a peak of industrial electrical protection, combining advanced technology with robust construction. Whether utilized in power distribution networks, manufacturing facilities, or critical infrastructure, the XS1600NE delivers unmatched performance, reliability, and safety. Its high interruption capacity, comprehensive auxiliary functions, and durable design make it an important component in modern industrial electrical systems.
For a comprehensive understanding of Terasaki's circuit breaker range, you might also explore this product, the Terasaki Xh100Ns 3 Pole Circuit Breaker AC690V 5060Hz . Like the Terasaki Xs1600Ne 3 Pole Circuit Breaker AC690V 5060Hz 1600Amp, it offers robust performance and reliability for critical applications. Both models are designed to ensure high safety standards and efficient operation, making them ideal choices for demanding industrial conditions.
