Schneider Electric/Merlin Gerin Ns1250H Circuit Breaker Trip Unit 1250Amp

No reviews yet Write a Review
$0.00
Condition:
Used
SKU:
73681
Shipping:
Free Shipping
Quantity Type:
PCS
Short Description:

Schneider Electric/Merlin Gerin Ns1250H Circuit Breaker Trip Unit 1250Amp
Schneider Electric
Merlin Gerin
Circuit Breaker Trip Unit
Compact
Ns1250H
Ui: 750V
Uimp: 8Kv
Ics= 50% Icu

Out of stock
Get a Quote
5 customers are viewing this product
Specification Details
Product Name Schneider Electric/Merlin Gerin Ns1250H Circuit Breaker Trip Unit 1250Amp
Brand Schneider Electric
Model Merlin Gerin
Type Circuit Breaker Trip Unit
Series Compact
Model Number Ns1250H
Ui 750V
Uimp 8kV
Ics 50% Icu
Icw 25Ka/0.5S
Category Cat.B
Standard IEC 60947-2
Trip Unit Micrologic 2.0A
Rated Current (In) 1250A
Catalog Number W09443
Product Code 9Tut0011382
Control Circuit Voltage (Tcde/Rctl) 200-240 Vac
Operating Circuit Voltage (Mn/Rr) 200-250 Vac/Vdc
Batch Number B105678875006
Serial Number H09477
Manufacturing Code 33024/Ghj10570Aa
Unique Product Identifier 094770708101013701123
Product Part Number Pp: 1400266442
Compliance Certification E161835
Secondary Certification E63335
Assembly Location Assembled in Singapore
Weight 15.300 Kg

NS1250H Circuit Breaker Trip Unit



Schneider Electric/Merlin Gerin NS1250H Circuit Breaker Trip Unit

The Schneider Electric/Merlin Gerin NS1250H Circuit Breaker Trip Unit is a robust and reliable solution for safeguarding electrical systems. With a supposed current (In) of 1250A and a voltage rating (Ui) of 750V, this circuit breaker is designed to handle significant electrical loads, ensuring the smooth operation of your equipment. The unit's high impulse withstands voltage (Uimp) of 8kV and short-circuit breaking capacity (Ics) at 50% of Icu highlight its ability to withstand and interrupt high fault currents, making it an essential component in industrial and commercial contexts. The NS1250H is compliant with the IEC 60947-2 standard, ensuring it meets international safety and performance benchmarks. Additionally, its Icw rating of 25kA for 0.5 seconds and Category B classification signify its durability and reliability in high-stress scenarios.

Advanced Features with Micrologic 2.0A Technology

Equipped with Micrologic 2.0A technology, the Schneider Electric/Merlin Gerin NS1250H Circuit Breaker offers advanced protection and monitoring capabilities. This intelligent trip unit provides precise adjustments and real-time monitoring, enhancing the safety and efficiency of your electrical distribution system. The trip unit’s flexibility in control voltage options, including Tcde/Rctl (200-240 Vac) and Mn/Rr (200-250 Vac/Vdc), allows for versatile installation and integration into various electrical systems. The device is designed with robust components and is assembled in Singapore, ensuring high-quality manufacturing standards. With a weight of 15.300 kg, it is solid yet manageable for installation and maintenance, making it a practical choice for engineers and electricians.

The Schneider Electric/Merlin Gerin NS1250H Circuit Breaker Trip Unit is manufactured to deliver long-term reliability and efficiency in diverse conditions. Its comprehensive design includes part numbers W09443, 9Tut0011382, and identifiers such as B105678875006 and H09477, which help in ensuring precise compatibility and ease of replacement in existing systems. The product’s high performance is backed by certifications like E161835 and E63335, underscoring its adherence to quality and safety standards. The part number 33024/Ghj10570Aa and code 094770708101013701123 reflect its unique specifications and traceability, ensuring authenticity and reliability. Additionally, the Pp number 1400266442 facilitates inventory management and serviceability. Overall, the NS1250H circuit breaker trip unit is a dependable and efficient solution for protecting your electrical infrastructure, providing operational stability.

For those interested in the Schneider Electric/Merlin Gerin NS1250H Circuit Breaker Trip Unit, you may also want to consider the Schneider Electric Merlin Gerin NS100L Circuit Breaker 750V 40/100A . This model offers excellent protection and reliability for lower current applications, maintaining the same high standards of performance and safety. Both models are designed to meet rigorous IEC 60947-2 standards and provide efficient solutions for your electrical distribution needs.
