Schneider Electric Nsx 160F Circuit Breaker/Switch-disconnector
Schneider Electric Industries Sas
Circuit Breaker/Switch-disconnector
Compact
Nsx 160F
Ui 800 V
Uimp 8 Kv
| Item | Details |
|---|---|
| Product | Schneider Electric NSX 160F Circuit Breaker/Switch-disconnector |
| Manufacturer | Schneider Electric Industries SAS |
| Type | Circuit Breaker/Switch-disconnector |
| Series | Compact NSX 160F |
| Rated Voltage (Ui) | 800 V |
| Impulse Voltage (Uimp) | 8 kV |
| Frequency | 50/60 Hz |
| Category | Cat A |
| IEC/EN Standard | IEC/EN 60947-2 |
| Rated Current (Ir) | 88/125 A |
| Short-Circuit Rating (Im) | 1250 A |
| Thermal Magnetic Rating (Tm) | 125 D |
| Rated Current at 40°C | 125 A/40°C |
| Part Number | LV430631 10002114 |
| Other Reference | K14114 |
| Additional Part Number | 994076C |
| Weight | 1.860 Kg |
Schneider Electric NSX 160F Circuit Breaker/Switch-Disconnector is highly reliable and versatile since it can be designed to provide maximum protection and control in different electrical distribution systems. This has been designed and manufactured by Schneider Electric Industries SAS and comes in a compact circuit breaker that meets the challenging industrial and commercial conditions of modern applications.
The NSX 160F has a 800V short-circuit withstand rating of 8 kV. It is assured of having enough electrical strength to handle its enormous electrical loads. It boasts a rated current (Ir) of 88/125A, while the maximum current rating, Im, is at 1250A, and it encompasses several types of applications. The circuit breaker conforms to the requirements of IEC/EN 60947-2 standards about reliability and safety.
The NSX 160F has a weight of 1.860 kg, designed to be easily installed and integrated into existing systems. Thus, this product is just right for professionals looking for reliable circuit protection solutions.
1. High Voltage Rating : This device is given a high-voltage rating that is permitted for operating up to 800 V, so that it can support any variety of electrical systems.
2. Short-Circuit Withstand Rating : Uimp of 8 kV adds reliable short-circuit conditions safety.
3. Versatile Current Ratings : The rated current of 88/125A and maximum permissible current up to 1250 A makes it possible to handle several loads.
4. Compact Design : Engineered for easy installation within the limited space environment in which there will be no compromise in performance.
5. Frequency Compatibility : Designed for use within 50Hz as well as 60Hz electrical systems that provide versatility.
6. Durable Construction : Built to withstand demanding industrial conditions, ensuring long-term reliability.
7. Quality Assurance : Manufactured by Schneider Electric, known for high-quality electrical solutions.
8. Lightweight : Weighs only 1.860 kg, facilitating easy handling and installation.
9. Safety Compliance : Compliant with IEC/EN 60947-2 standards for safety and reliability.
10. Efficient Operation : Designed to provide effective protection and control in electrical distribution networks.
1. Industrial Electrical Systems : Functions in the factories and units of manufacturing to protect circuits.
2. Commercial Buildings : Used in the electrical distribution panels of buildings for safety and reliability.
3. Data Centers : In critical power systems, it ensures uninterrupted service.
4. Renewable Energy Systems : Used in both solar and wind energy systems to ensure effective circuit protection.
5. HVAC Equipments : Functions with heating, ventilation, and air-conditioning systems to regulate the circuits.
6. Pumping Stations : Functions in the water and wastewater treatment units for efficient running of operation.
7. Process Control Systems : In process industries they are used to maintain optimal operating conditions.
8. Marine Applications : Shipboard electrical systems for safety and efficiency purposes.
9. Construction Equipment : Used in heavy machinery for protection of the electrical component.
10. Transportation Systems : Rail and public transportation systems for safety purposes.
Ensure dependable circuit protection with the Schneider Electric NSX 160F Circuit Breaker/Switch-Disconnector. Like Related Products Reach out to Aeliya Marine today for more details and customized solutions!
