Hyundai Hat06 Air Circuit Breaker 630A 50/60 Hz 690V
Hyundai Heavy Industries Co., Ltd.
Air Circuit Breaker
Hat06
Poles: 3P
Operational Volt.(Ue): 690V Ac
Rated Frequency: 50/60 Hz
R
| Specification | Details |
|---|---|
| Product Name | Hyundai Hat06 Air Circuit Breaker 630A 50/60 Hz 690V |
| Manufacturer | Hyundai Heavy Industries Co., Ltd. |
| Type | Air Circuit Breaker |
| Model | Hat06 |
| Poles | 3P |
| Operational Voltage (Ue) | 690V AC |
| Rated Frequency | 50/60 Hz |
| Rated Current | 630 A |
| Standards | IEC 60947-2, ANSI 37-13, EN 60947-2, VDE 0660 |
| Ambient Temperature | 45°C |
| Over-current Trip | AOR-1S-AS |
| Base Current (Io) | 160 A |
| CT Rating (Ict) | 320/5A |
| Rated Frequency | 50/60 Hz |
| DC Voltage | 24V |
| AC/DC Voltage | 100-250V |
| UVT Trip Device | Type: HATS-T (I), Voltage: 200V-240V |
| Auxiliary Switch | Type: 5A 5B |
| Charge Up Switch | HATS-CS, 3A 3B |
| Magnet Hold Trigger | Included |
| Country of Origin | Made in Korea |
| Weight | 77.300 Kg |
Hyundai HAT06 Air Circuit Breaker, an advanced solution designed and manufactured by Hyundai Heavy Industries Co., Ltd., a global leader in industrial technology and innovation. This advanced air circuit breaker is designed to deliver exceptional performance, reliability, and safety in various industrial and commercial applications. With its robust construction and adherence to international standards, the Hyundai HAT06 is the ideal choice for protecting electrical systems from overcurrent and short-circuits conditions.
The HAT06 Air Circuit Breaker is designed for high-voltage applications, operating at 690V AC with a rated current of 630A. It features a 3-Pole configuration, making it suitable for three-phase power systems commonly used in industrial conditions. The breaker supports a rated frequency of 50/60 Hz, ensuring compatibility with different power grids and systems worldwide. Additionally, it meets the requirements of international standards such as IEC 60947-2, ANSI 37-13, EN 60947-2, and VDE 0660, guaranteeing high performance, safety, and reliability.
One of the key features of the Hyundai HAT06 is its advanced over-current trip mechanism, designated as AOR-1S-AS. This mechanism provides rapid and accurate detection of overcurrent conditions, ensuring the protection of electrical equipment and systems. The breaker has a base current (Io) of 160A and a current transformer (CT) rating of 320/5A, offering precise measurement and control capabilities. The unit is designed to operate in ambient temperatures up to 45°C, making it suitable for use in various environmental conditions. The HAT06 also includes a UVT (Under Voltage Trip) device, type HATS-T (I), with a voltage range of 200V-240V. This device enhances the safety of the electrical system by ensuring the breaker trips in the event of a significant voltage drop, preventing potential damage to equipment. Furthermore, the breaker is equipped with auxiliary switches, type 5A 5B, and charge-up switches, type HATS-CS, 3A 3B, providing additional control and monitoring capabilities. The magnet hold trigger feature ensures the breaker remains securely in the closed position during normal operation, enhancing system stability and reliability. Manufactured in Korea, the Hyundai HAT06 Air Circuit Breaker is built with high-quality materials and undergoes rigorous testing to ensure it meets Hyundai's exacting standards for performance and durability. Weighing 77.300 kg, this breaker is designed for easy installation and maintenance, making it an ideal choice for various industrial applications, including manufacturing plants, power distribution networks, commercial buildings, and more.
In terms of applications, the Hyundai HAT06 Air Circuit Breaker is versatile and suitable for a wide range of industries. In manufacturing plants, it provides reliable protection for machinery and equipment, ensuring continuous operation and minimizing downtime. In power distribution networks, it helps maintain the stability and safety of the electrical grid by preventing overcurrent and short-circuit conditions. In commercial buildings, the breaker safeguards critical systems such as HVAC, lighting, and security, ensuring the safety and comfort of occupants. Moreover, the Hyundai HAT06 is an excellent choice for renewable energy applications, such as wind and solar power installations. Its robust design and high performance ensure reliable operation in these demanding situations, protecting equipment from electrical faults and enhancing the overall efficiency of the energy system. Additionally, the breakers compliance with international standards makes it suitable for use in various regions, providing a versatile and reliable solution for global applications.
The Hyundai HAT06 Air Circuit Breaker is also an ideal solution for data centers, where maintaining a stable and reliable power supply is crucial. The breaker's advanced features, including its over-current trip mechanism and UVT device, ensure the protection of sensitive electronic equipment, preventing costly downtime and data loss. Furthermore, its auxiliary switches and charge-up switches provide enhanced control and monitoring capabilities, allowing for efficient management of the electrical system.
The Hyundai HAT06 Air Circuit Breaker is a high-performance, reliable, and versatile solution for protecting electrical systems in various industrial and commercial applications. Its robust construction, advanced features, and compliance with international standards make it the ideal choice for ensuring the safety and reliability of your electrical infrastructure. Whether you are looking to protect critical systems in a manufacturing plant, power distribution network, commercial building, or renewable energy installation, the Hyundai HAT06 is the perfect solution.
For a more comprehensive solution to your circuit protection needs, consider exploring the. Hyundai HAT09 3 Pole Air Circuit Breaker, which offers enhanced features and higher current ratings. Discover more about the Hyundai HAT09 3 Pole Air Circuit Breaker and see how it can complement and enhance your electrical infrastructure alongside the Hyundai HAT06.
