Merlin Gerin Nt16 H1 Circuit Breaker Micrologic 2.0A 1600A
Merlin Gerin
Micrologic 2.0A
In= 1600A
Masterpact
Nt16 H1
Ui: 1000V
Uimp: 12Kv
| Specification | Details |
|---|---|
| Product Name | Merlin Gerin Nt16 H1 Circuit Breaker Micrologic 2.0A 1600A |
| Brand | Merlin Gerin |
| Trip Unit | Micrologic 2.0A |
| Rated Current (In) | 1600A |
| Frame Type | Masterpact |
| Model | Nt16 H1 |
| Ui | 1000V |
| Uimp | 12kV |
| Ue | 220/440V~ 480/690V~ |
| Icw | 42kA 42kA/1s |
| Ics | 100% Icu |
| Category | Cat.B |
| Standards | IEC 60947-2 50/60Hz |
| Motor Mechanism (Mch) | 200-240 Vac |
| Shunt Trip (Mx) | 200-250 Vac/Vdc |
| Shunt Trip (Mx-xf/ Sht-shc) | 200-250 V Ac-dc |
| Reference Numbers | W07123, 33662, E161835, E63335 Serie: 1204100677, 007112337574 33757/Ghj10113Aa H07112 |
| Weight | 36 Kg |
The Nt16 H1 Circuit Breaker with Micrologic 2.0A is a robust and reliable solution for managing electrical circuits in industrial settings. Designed by Schneider Electric under the Merlin Gerin brand, this circuit breaker is renowned for its high performance, durability, and advanced features that ensure safety and efficiency in power distribution systems. With a rated current of 1600A, it is suitable for a wide range of durable applications. The Merlin Gerin Nt16 H1 is equipped with the Micrologic 2.0A trip unit, which provides precise and reliable protection against overloads, short circuits, and other electrical faults. The Micrologic 2.0A offers advanced metering and monitoring capabilities, allowing operators to keep track of critical parameters and ensure optimal performance of the electrical system. One of the standout features of the Nt16 H1 is its high short time withstand current (Icw) of 42kA for 1 second. This capability ensures that the circuit breaker can handle significant fault currents without sustaining damage, thereby enhancing the safety and reliability of the power distribution network. Additionally, the circuit breakers rated service short-circuit breaking capacity (Ics) is 100% of its ultimate short-circuit breaking capacity (Icu), underscoring its robust performance under fault conditions.
The Merlin Gerin Nt16 H1 Circuit Breaker is designed to meet the demanding requirements of various industrial applications. Its versatile voltage ratings (220/440V AC and 480/690V AC) and high impulse withstand voltage (12kV) make it suitable for use in various conditions, including manufacturing plants, data centers, commercial buildings, and utility infrastructures. The breaker’s ability to operate efficiently at both 50Hz and 60Hz further broadens its applicability across different regions and standards. Compliance with the IEC 60947-2 standard ensures that the Merlin Gerin Nt16 H1 meets the highest safety and performance criteria for low-voltage switchgear and control gear. The Micrologic 2.0A trip unit integrated into the Nt16 H1 offers advanced control and monitoring features that enhance operational efficiency. Operators can access real-time data on electrical parameters, event logs, and diagnostic information, enabling proactive maintenance and rapid response to potential issues. This level of control helps to optimize the performance of the electrical system and minimize the risk of unplanned outages.
The Merlin Gerin Nt16 H1 Circuit Breaker with Micrologic 2.0A is a high-performance, reliable, and versatile solution for protecting and controlling electrical circuits in industrial settings. Its advanced features, robust specifications, and compliance with international standards make it an ideal choice for ensuring the safety and efficiency of power distribution systems. Whether used in manufacturing, commercial, or utility applications, the Nt16 H1 delivers exceptional performance.
For those looking for a similar high-performance circuit breaker, consider the here Merlin Gerin Nt16 H1 Micrologic 5.0A Circuit Breaker 1600A Mch 200-240 Vac , which offers enhanced protection features and advanced monitoring capabilities, ensuring reliable and efficient power distribution in industrial applications.
