Terasaki Electric At06 Air Circuit Breaker Aut-1Bs Uvt Trip Device 630A
Terasaki Electric Co., Ltd.
Tempower
Air Circuit Breaker
At06
Poles: 3
Voltage: 660 Vac
Frequency: 50/60Hz
Current: 630A
Specification | Details |
---|---|
Product Name | Terasaki Electric At06 Air Circuit Breaker Aut-1Bs Uvt Trip Device 630A |
Manufacturer | Terasaki Electric Co., Ltd. |
Model | At06 |
Type | Tempower Air Circuit Breaker |
Poles | 3 |
Voltage | 660 Vac |
Frequency | 50/60Hz |
Current | 630A |
Standard | IEC157-1-P-2 |
Breaking Capacity (With Inst) | 660V 22kA 550-600V 30kA 220-500V 35kA |
Short Time Current | 1 Sec: 35kA 3 Sec: 30kA |
Over-current Trip | AOR-1S-AS, Nqh9316A1 |
Base Current | Io: 246A |
CT Rating | ICT: 320/5A |
Rated Frequency | 50-60Hz |
Voltage (Auxiliary) | AC 100-125V AC 200-250V |
Magnet Hold Trigger | ATT-1 |
Auxiliary Switch | AXT-1C 3A3B |
RQU2057A1 | AXT-1AB 10P 5A 5B |
RQU2312A1 | UVT Trip Device Type: AUT-1BS Voltage: AC 200-240V |
BTUS0001A1 | Position Switch ALT-2PB RQU0437A1 ALT-1PB RQT9215A2 |
Accessories | Motor Charging: AC 220V Magnet Inst Trip: 3kA Under Voltage Trip: AC 220V Aux. Switch 5A 5B |
Origin | Made In Japan |
Weight | 83 Kg |
The Terasaki Electric At06 Air Circuit Breaker Aut-1Bs Uvt Trip Device, designed to meet the highest standards of electrical protection. Built by Terasaki Electric Co., Ltd., a renowned name in the industry, this air circuit breaker is ideal for demanding conditions requiring dependable electrical solutions. With its 660 Vac voltage capacity and a frequency of 50/60Hz, it delivers consistent performance across various applications.
Equipped with a robust IEC157-1-P-2 standard, the At06 breaker boasts breaking capacities, ensuring safety with 22Ka at 660V and up to 35Ka at lower voltages. Its short-time current handling capabilities of 35Ka for 1 second and 30Ka for 3 seconds make it suitable for handling sudden electrical surges effectively. The UVT trip device, type Aut-1Bs, operates seamlessly within AC200-240V, offering reliable protection against overcurrent situations.
For added functionality, the breaker includes essential accessories like the ATPS0005A2 auxiliary switch, enabling precise control and monitoring. Made in Japan, each unit embodies precision and quality craftsmanship, ensuring long-term performance and composure for operators. Weighing 83 Kg, it's designed for easy installation and maintenance, making it an ideal choice for industrial and commercial applications where reliability is vital.
For a high-performance solution similar to the Terasaki Electric At06 Air Circuit Breaker Aut-1Bs Uvt Trip Device 630A, consider exploring the Terasaki Electric At06 Air Circuit Breaker Aut-1Bs 630A . This breaker offers enhanced capacity and advanced features, making it an excellent choice for more demanding electrical protection needs.
