Terasaki Electric At06 Tempower Air Circuit Breaker 630A
Terasaki Electric Co., Ltd.
Tempower
Air Circuit Breaker
At06
Poles: 3
Operational Volt. (Ue): 690Vac
Rated Frequency: 50/60Hz
Rated Current (In): 630 A
St
| Specification | Details |
|---|---|
| Product Name | Terasaki Electric At06 Tempower Air Circuit Breaker 630A |
| Manufacturer | Terasaki Electric Co., Ltd. |
| Series | Tempower |
| Type | Air Circuit Breaker |
| Model | At06 |
| Poles | 3 |
| Ue | 690Vac |
| Rated Frequency | 50/60Hz |
| Rated Current (In) | 630 A |
| Standard | IEC947-2 |
| Utilization Category | B |
| Ics | 100% Icu |
| Icw | 1 Sec: 50Ka, 3 Sec: 45Ka |
| Catalogue Number | Atps0017-b |
| Ambient Temperature | 45°C |
| Motor Charging | DC125V |
| OCR | Io= 630A, Ict= 630A/5A |
| Under Voltage Trip | DC125V |
| Auxiliary Switch | 5A5B |
| Part Numbers | N160236-001, 97104-147 |
| Over-current Trip | Aor-1Bl-al |
| Io | 630A |
| Ict | 630/5A |
| Auxiliary Switch Model | Axt-1Ab, 10P 5A 5B |
| Magnet Hold Trigger | Att-1 |
| Trigger Model | Ta-8472-1-1 |
| Origin | Japan |
| Weight | 78 Kg |
When it comes to ensuring the reliability and safety of your electrical systems, the AT06 Tempower 3-Pole Air Circuit Breaker stands out as a top choice. Manufactured by Terasaki Electric Co., Ltd., this high-quality air circuit breaker is designed to meet the demands of modern electrical infrastructures, offering robust performance and advanced safety features.
Key Features
The Terasaki AT06 is a 3-pole air circuit breaker designed for high-voltage applications. It operates at an impressive 690Vac and is rated for a frequency range of 50/60Hz, making it versatile enough for various industrial conditions. With a rated current of 630A, this breaker is ideal for long-lasting applications that require reliable and consistent performance. This breaker complies with the IEC947-2 standard, ensuring it meets international safety and performance guidelines. Its utilization category B means it is suitable for a wide range of applications, offering flexibility and reliability. One of the standout features of the AT06 is its high short-circuit breaking capacity (Ics), which is 100% of its ultimate breaking capacity (Icu), ensuring it can handle fault conditions effectively.
Safety is an important concern in electrical systems, and the Terasaki AT06 does not disappoint. It boasts a short time withstand current (Icw) of 50kA for 1 second and 45kA for 3 seconds, ensuring it can handle high fault currents without damage. This durability is essential for protecting both the breaker and the connected equipment. The AT06 is designed to operate efficiently in various environmental conditions, with an ambient temperature rating of 45°C. This makes it suitable for use in different climates and industrial settings. The breaker includes a motor charging feature with a DC125V rating, ensuring it can be easily and quickly reset after a trip, minimizing downtime.
The Terasaki AT06 comes equipped with several advanced protection features to enhance safety and performance. It includes an over-current trip function (AOR-1Bl-al) to protect against excessive currents, safeguarding your electrical system from potential damage. The breaker also features an under-voltage trip mechanism rated at DC125V, which helps prevent damage caused by low voltage conditions. To ensure precise and accurate operation, the AT06 includes current transformers (CTs) with a rating of 630A/5A. These CTs provide reliable current measurement and protection, enhancing the overall performance of the breaker. The base current (Io) is set at 630A, ensuring consistent and stable operation under various load conditions.
The Terasaki AT06 is designed with a range of auxiliary and control features to enhance its functionality and ease of use. It includes auxiliary switches (5A 5B) that allow for additional control and monitoring options, making it easier to integrate into complex electrical systems. The auxiliary switch type Axt-1Ab includes 10 poles, providing flexibility in control and signaling applications. For added safety and convenience, the AT06 is equipped with a magnet hold trigger (Att-1) and a motor charging feature, ensuring it can be reset quickly and efficiently after a trip. This minimizes downtime and helps maintain the continuity of your operations.
The Terasaki AT06 Tempower Air Circuit Breaker is a top-tier choice for ensuring the safety and reliability of your electrical systems. With its high-voltage capability, robust safety features, and advanced protection mechanisms, it is an ideal solution for a wide range of industrial application
For a reliable alternative to the Terasaki Electric At06 Tempower Air Circuit Breaker 630A consider the Terasaki At06 Tempower Air Circuit Breaker 3 Poles 630A 50/60Hz. This model offers higher current capacity while maintaining the same high standards of safety and performance, making it ideal for more demanding industrial applications.
