Terasaki At06 3 Poles Air Circuit Breaker 630A 50/60Hz
Terasaki Electric Co., Ltd.
Tempower
Air Circuit Breaker
At06
Poles: 3
Voltage: 660 Vac
Frequency: 50/60Hz
Current: 630A
| Specification | Details |
|---|---|
| Product Name | Terasaki At06 3 Poles Air Circuit Breaker 630A 50/60Hz |
| Manufacturer | Terasaki Electric Co., Ltd. |
| Brand | Tempower |
| Type | Air Circuit Breaker |
| Model | At06 |
| Poles | 3 |
| Voltage | 660 Vac |
| Frequency | 50/60Hz |
| Current | 630A |
| Standard | Iec157-1-p-2 |
| Breaking Capacity (With Inst) | |
| - 660V | 22Ka |
| - 550-600V | 30Ka |
| - 220-500V | 35Ka |
| Short Time Current | |
| - 1 Sec | 35Ka |
| - 3 Sec | 30Ka |
| Model Number | Nqh9316A1 |
| Over-current Trip | Aor-1L-al |
| Base Current | Io: 500A |
| CT Rating | Ict: 630/5A |
| Rated Frequency | 50-60Hz |
| UVT Trip Device | |
| - Type | Aut-1Bd |
| - Voltage | Ac100~120 |
| Position Switch | Btus0001A1, Alt-2Pd |
| Model Number | Rqu0440A1 |
| Model Number | Alt-1Pt |
| Model Number | Ta-9214-1-1 |
| Magnet Hold Trigger | Att-1 |
| Auxiliary Switch | |
| - Axt-1C | 3A3B |
| Model Number | Rqu2057A1 |
| - Axt-a1B | 10P 5A 5B |
| Model Number | Rqu2312A1 |
| Accessories | |
| - Motor Charging | Ac 240V Dc |
| - Aor-4L | Io: 500A |
| - CT | 630A/5A |
| - Magnet Inst Trip | 15Ka |
| - Under Voltage Trip | Ac 110V |
| - Shunt Trip | Dc 24V |
| - Aux. Switch | 5A 5B |
| Model Number | Atps0005A2 |
| Country of Origin | Japan |
| Weight | 77.200 Kg |
The AT06 3 Poles Air Circuit Breaker is a robust and reliable solution for managing electrical circuits in various applications. Manufactured by Terasaki Electric Co., Ltd., a leading name in electrical solutions, this air circuit breaker is designed to provide superior performance and safety. The AT06 model operates at a voltage of 660 Vac with a frequency range of 50/60Hz, ensuring versatility in different electrical conditions. With a current rating of 630A, it is well-suited for both industrial and commercial use, offering protection and efficiency in managing electrical loads. The circuit breaker adheres to the IEC157-1-p-2 standard, underlining its compliance with international safety and performance norms.
Safety is a dominant feature of the Terasaki AT06 3 Poles Air Circuit Breaker. It boasts an impressive breaking capacity, with ratings of 22Ka at 660V, 30Ka at 550-600V, and 35Ka at 220-500V, ensuring effective interruption of excessive currents to protect electrical systems from damage. Additionally, the short-time current ratings are 35Ka for 1 second and 30Ka for 3 seconds, providing reliable performance during transient faults. The over-current trip feature, identified as AOR-1L-AL, and the base current of Io: 500A, further enhance its protective capabilities. The circuit breaker CT rating of Ict: 630/5A and its rated frequency of 50-60Hz ensure accurate current measurement and protection.
The Terasaki AT06 3 Poles Air Circuit Breaker is equipped with various trip and switch mechanisms to cater to different operational needs. It includes a UVT trip device type AUT-1BD with a voltage range of AC100~120, and a magnet hold trigger ATT-1 for secure and stable operation. The auxiliary switch AXT-1C with 3A3B configuration and the AXT-A1B with a 10P 5A 5B configuration offer versatile control options. The inclusion of a motor charging unit for AC 240V DC ensures smooth and efficient resetting of the breaker. These features make the AT06 model adaptable to various electrical system requirements, enhancing its utility and reliability in different scenarios.
The Terasaki AT06 3 Poles Air Circuit Breaker is designed for long-lasting performance and ease of use. With a weight of 77.200 kg, it is sturdy yet manageable for installation in different settings. Its robust construction ensures durability and reliability, even in demanding environments. The breaker also supports additional accessories like the AOR-4L, with an Io of 500A and a CT of 630A/5A, and magnet instant trip rated at 15Ka. It includes an under-voltage trip device for AC 110V and a shunt trip for DC 24V, further enhancing its versatility. The auxiliary switch with 5A 5B configuration provides additional control options, making it a comprehensive solution for various electrical protection needs.
If you're looking for a similar product to the Terasaki At06 3 Poles Air Circuit Breaker 630A 50/60Hz, consider exploring our range of Terasaki air circuit breakers designed for robust performance and reliability. Whether you need solutions for different current ratings, voltage requirements, or specific operational features like advanced trip mechanisms and auxiliary switches, our lineup ensures you find the right fit for your electrical protection needs. Explore here Terasaki AT06 Tempower Air Circuit Breaker 3 Poles 630A 50/60Hz .
