Terasaki At06 Tempower Air Circuit Breaker 3 Poles 630A 50/60Hz
Terasaki Electric Co., Ltd.
Tempower
Air Circuit Breaker
At06
Poles: 3
Voltage: 660 Vac
Frequency: 50/60Hz
Current: 630A
| Specification | Details |
|---|---|
| Product Name | Terasaki At06 Tempower Air Circuit Breaker 3 Poles 630A 50/60Hz |
| Manufacturer | Terasaki Electric Co., Ltd. |
| Model | Tempower At06 |
| Poles | 3 |
| Voltage | 660 Vac |
| Frequency | 50/60Hz |
| Current | 630A |
| Standard | IEC 157-1-P-2 |
| Breaking Capacity (With Inst) | 660V: 22kA 550-600V: 30kA 220-500V: 35kA |
| Short Time Current | 1 Sec: 35kA 3 Sec: 30kA |
| Over-current Trip | AOR-1L-AL |
| Base Cur. Io | 500A |
| CT Rating ICT | 630/5A |
| Rated Frequency | 50-60Hz |
| Magnet Hold Trigger | ATT-1 |
| Auxiliary Switch | AXT-1C (3A3B) RQU2057A1 AXT-1AB (10P 5A 5B) RQU2312A1 |
| UVT Trip Device | Type: AUT-1BD BTUS0001A1 |
| Motor Charging | AC240V |
| Io | 500A |
| CT | 630A/5A |
| Magnet Inst Trip | 15 kA |
| Under Voltage Trip | AC 110V |
| Shunt Trip | DC24V |
| Aux. Switch | 5A 5B ATPS0005A2 BTDS0004-A1 |
| Origin | Made in Japan |
| Weight | 77.200 kg |
The Terasaki At06 Tempower Air Circuit Breaker, manufactured by Terasaki Electric Co., Ltd. Designed for robust performance in demanding industrial conditions, this 3-pole circuit breaker is exactly crafted to deliver reliability and efficiency.
Key Features:
1.Reliable Power Distribution: The At06 operates effortlessly at 660 Vac with a frequency of 50/60Hz, ensuring stable performance across varying electrical loads. With a current rating of 630A, it meets the rigorous demands of industrial applications.
2.High Breaking Capacity: Compliant with IEC157-1-P-2 standards, this circuit breaker boasts impressive breaking capacities:
At 660V: 22kA
At 550-600V: 30kA
At 220-500V: 35kA
2.Short Time Current Ratings: In critical situations, the At06 stands strong with short-time current ratings:
1 second: 35kA
3 seconds: 30kA
3.Advanced Protection Mechanisms: Equipped with an Over-current Trip (AOR-1L-AL) mechanism and a Magnetic Hold Trigger (ATT-1), this breaker ensures swift response to overloads and short circuits, safeguarding your equipment and personnel.
4.Auxiliary Switches: Featuring an auxiliary switch configuration (AXT-1C 3A3B), the At06 supports flexible control and monitoring capabilities, enhancing operational efficiency.
5.UVT Trip Device: The integrated UVT Trip Device (Type: AUT-1BD BTUS0001A1) provides additional protection against voltage fluctuations, further securing your electrical installations.
Applications:
Ideal for a wide range of applications, including:
1.Industrial Facilities: Ensure uninterrupted power distribution in manufacturing plants and production lines.
2.Commercial Buildings: Safeguard electrical systems in office complexes and shopping centers.
3.Infrastructure Projects: Reliable performance for critical infrastructure projects such as airports, hospitals, and data centers.
4.Renewable Energy: Support renewable energy installations with dependable circuit protection solutions.
The Terasaki At06 Tempower Air Circuit Breaker sets a new standard in electrical circuit protection with its exceptional performance, advanced features, and durable construction. Whether you're upgrading an existing system or installing new infrastructure, rely on the At06 to deliver reliability.
For robust electrical protection and reliable power management in industrial applications, look no further than the Terasaki At06 Air Circuit Breaker 3 Pole 630A 50/60Hz . Manufactured to meet high standards of performance and safety, the At06 model ensures uninterrupted operation and enhanced system reliability. Whether you're upgrading existing infrastructure or equipping new facilities, the At06 stands out for its advanced features and durable construction, making it an ideal choice for demanding industrial applications.
